| | 17-4PH Stainless Steel
Rods
Order 17-4PH
Rods Online - Click Here
Technical Data
| 17-4PH
Stainless Steel Rods |
| Precision
Ground Finish |
Tight-Tolerance
Undersize Rods-Precision Ground Finish. Annealed. ASTM A564.
Type 17-4 is a martensitic precipitation
hardening (maraging) steel that combines high strength and hardness
with excellent corrosion resistance. A simple one-step aging treatment
in the range of 900 to 1150° hardens the alloy to its design strength
levels.
Also known as type 630, it can be
precipitation hardened by a low cost treatment. 630 is magnetic in
both the solution annealed and precipitation hardened conditions.
|
| Straightness
Tolerance .001"/Foot. Diameter Tolerance -.0005", Length
tolerance +/- 1/32" |
| Stock
# |
Diameter
Inch |
Length
Inch |
Price
Each |
| MR-5876 |
.125" |
12" |
$13.84 |
| MR-5890 |
.125" |
36" |
$34.62 |
| MR-5904 |
.125" |
72" |
$57.70 |
| MR-5877 |
.1562" |
12" |
$15.78 |
| MR-5891 |
.1562" |
36" |
$39.48 |
| MR-5905 |
.1562" |
72" |
$65.80 |
| MR-5878 |
.1875" |
12" |
$18.82 |
| MR-5892 |
.1875" |
36" |
$47.04 |
| MR-5906 |
.1875" |
72" |
$78.40 |
| MR-5879 |
.250" |
12" |
$19.74 |
| MR-5893 |
.250" |
36" |
$48.30 |
| MR-5907 |
.250" |
72" |
$81.32 |
| MR-5880 |
.3125" |
12" |
$20.16 |
| MR-5894 |
.3125" |
36" |
$50.42 |
| MR-5908 |
.3125" |
72" |
$84.04 |
| MR-5881 |
.375" |
12" |
$22.44 |
| MR-5895 |
.375" |
36" |
$56.12 |
| MR-5909 |
.375" |
72" |
$93.52 |
| MR-5882 |
.4375" |
12" |
$25.76 |
| MR-5896 |
.4375" |
36" |
$62.00 |
| MR-5910 |
.4375" |
72" |
$108.94 |
| MR-5883 |
.500" |
12" |
$31.66 |
| MR-5897 |
.500" |
36" |
$64.18 |
| MR-5911 |
.500" |
72" |
$113.44 |
| MR-5884 |
.625" |
12" |
$36.98 |
| MR-5898 |
.625" |
36" |
$77.46 |
| MR-5912 |
.625" |
72" |
$137.36 |
| MR-5885 |
.750" |
12" |
$44.10 |
| MR-5899 |
.750" |
36" |
$90.24 |
| MR-5913 |
.750" |
72" |
$177.64 |
| MR-5886 |
.875" |
12" |
$51.26 |
| MR-5900 |
.875" |
36" |
$117.88 |
| MR-5914 |
.875" |
72" |
$205.02 |
| MR-5887 |
1.00" |
12" |
$65.26 |
| MR-5901 |
1.00" |
36" |
$150.10 |
| MR-5915 |
1.00" |
72" |
$261.04 |
| MR-5888 |
1.25" |
12" |
$94.26 |
| MR-5902 |
1.25" |
36" |
$216.80 |
| MR-5916 |
1.25" |
72" |
$377.04 |
| MR-5889 |
1.50" |
12" |
$115.08 |
| MR-5903 |
1.50" |
36" |
$264.68 |
| MR-5917 |
1.50" |
72" |
$460.30 |
Prices are subject to change
due to fluctuating market conditions. | |
|
