Steel Nylon Tip Set Screws
| Alloy Steel Nylon Tip Set Screws, -50° to 250°, Rockwell C28, ASME B18.3 |
||||||||
Thread Length:  |
Tip Length: |
Tip Diameter: |
||||||
| Part # | Threads | Thread Length | Tip Diameter | Tip Length | Drive Size | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| SSS-1063 | 2-56 | 1/8" | 0.031" | 0.031" | 0.035" | 10 | $14.96 | Add to Order |
| SSS-1064 | 2-56 | 1/4" | 0.031" | 0.031" | 0.035" | 10 | $15.40 | Add to Order |
| SSS-1065 | 4-40 | 1/8" | 0.063" | 0.031" | 0.050" | 10 | $12.60 | Add to Order |
| SSS-1066 | 4-40 | 3/16" | 0.063" | 0.031" | 0.050" | 10 | $20.22 | Add to Order |
| SSS-1067 | 4-40 | 1/4" | 0.063" | 0.031" | 0.050" | 10 | $7.20 | Add to Order |
| SSS-1068 | 4-40 | 3/8" | 0.063" | 0.031" | 0.050" | 10 | $8.50 | Add to Order |
| SSS-1069 | 6-32 | 1/8" | 0.063" | 0.031" | 1/16" | 10 | $13.78 | Add to Order |
| SSS-1070 | 6-32 | 3/16" | 0.063" | 0.031" | 1/16" | 10 | $8.40 | Add to Order |
| SSS-1071 | 6-32 | 1/4" | 0.063" | 0.031" | 1/16" | 10 | $6.00 | Add to Order |
| SSS-1072 | 6-32 | 3/8" | 0.063" | 0.031" | 1/16" | 10 | $7.80 | Add to Order |
| SSS-1073 | 6-32 | 1/2" | 0.063" | 0.031" | 1/16" | 10 | $8.13 | Add to Order |
| SSS-1074 | 8-32 | 1/8" | 0.094" | 0.047" | 5/64" | 10 | $9.10 | Add to Order |
| SSS-1075 | 8-32 | 3/16" | 0.094" | 0.047" | 5/64" | 10 | $9.10 | Add to Order |
| SSS-1076 | 8-32 | 1/4" | 0.094" | 0.047" | 5/64" | 25 | $18.69 | Add to Order |
| SSS-1077 | 8-32 | 3/8" | 0.094" | 0.047" | 5/64" | 10 | $5.25 | Add to Order |
| SSS-1078 | 8-32 | 1/2" | 0.094" | 0.047" | 5/64" | 10 | $8.40 | Add to Order |
| SSS-1079 | 8-32 | 5/8" | 0.094" | 0.047" | 5/64" | 10 | $7.70 | Add to Order |
| SSS-1080 | 10-24 | 3/16" | 0.094" | 0.047" | 3/32" | 10 | $12.99 | Add to Order |
| SSS-1081 | 10-24 | 1/4" | 0.094" | 0.047" | 3/32" | 25 | $13.00 | Add to Order |
| SSS-12605 | 10-24 | 5/16" | 0.094" | 0.047" | 3/32" | 10 | $19.03 | Add to Order |
| SSS-1082 | 10-24 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $6.50 | Add to Order |
| SSS-1083 | 10-24 | 1/2" | 0.094" | 0.047" | 3/32" | 10 | $7.15 | Add to Order |
| SSS-1084 | 10-24 | 3/4" | 0.094" | 0.047" | 3/32" | 10 | $9.94 | Add to Order |
| SSS-1085 | 10-32 | 3/16" | 0.094" | 0.047" | 3/32" | 10 | $9.45 | Add to Order |
| SSS-1086 | 10-32 | 1/4" | 0.094" | 0.047" | 3/32" | 25 | $16.88 | Add to Order |
| SSS-1087 | 10-32 | 5/16" | 0.094" | 0.047" | 3/32" | 10 | $8.40 | Add to Order |
| SSS-1088 | 10-32 | 3/8" | 0.094" | 0.047" | 3/32" | 10 | $7.00 | Add to Order |
| SSS-1089 | 10-32 | 1/2" | 0.094" | 0.047" | 3/32" | 10 | $7.56 | Add to Order |
| SSS-1090 | 10-32 | 3/4" | 0.094" | 0.047" | 3/32" | 10 | $8.08 | Add to Order |
| SSS-1091 | 1/4"-20 | 1/4" | 0.125" | 0.063" | 1/8" | 25 | $14.00 | Add to Order |
| SSS-1092 | 1/4"-20 | 5/16" | 0.125" | 0.063" | 1/8" | 10 | $7.70 | Add to Order |
| SSS-1093 | 1/4"-20 | 3/8" | 0.125" | 0.063" | 1/8" | 10 | $7.00 | Add to Order |
| SSS-1094 | 1/4"-20 | 1/2" | 0.125" | 0.063" | 1/8" | 10 | $7.00 | Add to Order |
| SSS-1095 | 1/4"-20 | 5/8" | 0.125" | 0.063" | 1/8" | 10 | $8.80 | Add to Order |
| SSS-1096 | 1/4"-20 | 3/4" | 0.125" | 0.063" | 1/8" | 10 | $9.00 | Add to Order |
| SSS-1097 | 1/4"-20 | 1" | 0.125" | 0.063" | 1/8" | 10 | $10.35 | Add to Order |
| SSS-1098 | 1/4"-20 | 1 1/4" | 0.125" | 0.063" | 1/8" | 5 | $16.80 | Add to Order |
| SSS-1099 | 1/4"-20 | 1 1/2" | 0.125" | 0.063" | 1/8" | 5 | $15.75 | Add to Order |
| SSS-1100 | 1/4"-28 | 1/4" | 0.125" | 0.063" | 1/8" | 25 | $14.06 | Add to Order |
| SSS-1101 | 1/4"-28 | 3/8" | 0.125" | 0.063" | 1/8" | 25 | $16.34 | Add to Order |
| SSS-1102 | 1/4"-28 | 1/2" | 0.125" | 0.063" | 1/8" | 10 | $8.70 | Add to Order |
| SSS-1103 | 5/16"-18 | 1/4" | 0.188" | 0.094" | 5/32" | 10 | $12.64 | Add to Order |
| SSS-1104 | 5/16"-18 | 5/16" | 0.188" | 0.094" | 5/32" | 10 | $8.80 | Add to Order |
| SSS-1105 | 5/16"-18 | 3/8" | 0.188" | 0.094" | 5/32" | 10 | $8.77 | Add to Order |
| SSS-1106 | 5/16"-18 | 1/2" | 0.188" | 0.094" | 5/32" | 10 | $9.63 | Add to Order |
| SSS-1107 | 5/16"-18 | 3/4" | 0.188" | 0.094" | 5/32" | 10 | $11.48 | Add to Order |
| SSS-1108 | 5/16"-18 | 1" | 0.188" | 0.094" | 5/32" | 10 | $15.21 | Add to Order |
| SSS-1109 | 5/16"-24 | 3/8" | 0.188" | 0.094" | 5/32" | 10 | $8.80 | Add to Order |
| SSS-1110 | 3/8"-16 | 1/4" | 0.188" | 0.094" | 3/16" | 10 | $25.07 | Add to Order |
| SSS-1111 | 3/8"-16 | 3/8" | 0.188" | 0.094" | 3/16" | 10 | $8.92 | Add to Order |
| SSS-1112 | 3/8"-16 | 1/2" | 0.188" | 0.094" | 3/16" | 10 | $9.50 | Add to Order |
| SSS-1113 | 3/8"-16 | 3/4" | 0.188" | 0.094" | 3/16" | 10 | $13.20 | Add to Order |
| SSS-1114 | 3/8"-16 | 1" | 0.188" | 0.094" | 3/16" | 10 | $14.50 | Add to Order |
| SSS-1115 | 3/8"-24 | 3/8" | 0.188" | 0.094" | 3/16" | 10 | $9.90 | Add to Order |
| SSS-1116 | 3/8"-24 | 1/2" | 0.188" | 0.094" | 3/16" | 10 | $10.73 | Add to Order |
| SSS-1117 | 1/2"-13 | 1/2" | 0.25" | 0.125" | 1/4" | 5 | $23.52 | Add to Order |
| SSS-1118 | 1/2"-13 | 3/4" | 0.25" | 0.125" | 1/4" | 5 | $25.33 | Add to Order |
| SSS-1119 | 1/2"-13 | 1" | 0.25" | 0.125" | 1/4" | 5 | $12.60 | Add to Order |
| Rev. 08-23, 04-23, 11-22, 09-22 | ||||||||
