Metric Steel Nylon Tip Set Screws

Part #	Threads	Pitch	Thread Length	Tip Diameter	Tip Length	Drive Size	Pkg. Qty.	Pkg. Price	Order Online
Metric Alloy Steel Nylon Tip Set Screws, -50° to 250°, Rockwell C28, ASME B18.3.6M, ASTM F912
Thread Length:				Tip Length:			Tip Diameter:
SSS-1120	M3	0.5 mm	3 mm	1.6 mm	0.8 mm	1.5 mm	5	$8.45	Add to Order
SSS-1121	M3	0.5 mm	4 mm	1.6 mm	0.8 mm	1.5 mm	5	$8.25	Add to Order
SSS-1122	M3	0.5 mm	5 mm	1.6 mm	0.8 mm	1.5 mm	5	$8.39	Add to Order
SSS-1123	M3	0.5 mm	6 mm	1.6 mm	0.8 mm	1.5 mm	5	$8.25	Add to Order
SSS-1124	M4	0.7 mm	4 mm	2.4 mm	1.2 mm	2 mm	5	$7.26	Add to Order
SSS-1125	M4	0.7 mm	6 mm	2.4 mm	1.2 mm	2 mm	5	$7.80	Add to Order
SSS-12606	M4	0.7 mm	8 mm	2.4 mm	1.2 mm	2 mm	5	$7.80	Add to Order
SSS-1126	M4	0.7 mm	10 mm	2.4 mm	1.2 mm	2 mm	5	$7.32	Add to Order
SSS-1127	M5	0.8 mm	5 mm	2.4 mm	1.2 mm	2.5 mm	5	$7.80	Add to Order
SSS-1128	M5	0.8 mm	6 mm	2.4 mm	1.2 mm	2.5 mm	5	$7.50	Add to Order
SSS-1129	M5	0.8 mm	8 mm	2.4 mm	1.2 mm	2.5 mm	5	$7.48	Add to Order
SSS-1130	M6	1 mm	6 mm	3.2 mm	1.6 mm	3 mm	5	$7.70	Add to Order
SSS-1131	M6	1 mm	8 mm	3.2 mm	1.6 mm	3 mm	5	$8.40	Add to Order
SSS-1132	M6	1 mm	10 mm	3.2 mm	1.6 mm	3 mm	5	$7.98	Add to Order
SSS-1133	M6	1 mm	12 mm	3.2 mm	1.6 mm	3 mm	5	$8.45	Add to Order
SSS-1134	M6	1 mm	16 mm	3.2 mm	1.6 mm	3 mm	5	$8.80	Add to Order
SSS-1135	M8	1.25 mm	6 mm	4.8 mm	2.4 mm	4 mm	1	$4.65	Add to Order
SSS-1136	M8	1.25 mm	8 mm	4.8 mm	2.4 mm	4 mm	5	$7.80	Add to Order
SSS-1137	M8	1.25 mm	10 mm	4.8 mm	2.4 mm	4 mm	5	$8.14	Add to Order
SSS-1138	M8	1.25 mm	12 mm	4.8 mm	2.4 mm	4 mm	5	$8.20	Add to Order
SSS-1139	M8	1.25 mm	16 mm	4.8 mm	2.4 mm	4 mm	5	$8.55	Add to Order
SSS-1140	M8	1.25 mm	20 mm	4.8 mm	2.4 mm	4 mm	5	$8.23	Add to Order
SSS-1141	M10	1.5 mm	10 mm	4.8 mm	2.4 mm	5 mm	5	$8.67	Add to Order
SSS-1142	M10	1.5 mm	16 mm	4.8 mm	2.4 mm	5 mm	5	$8.76	Add to Order
SSS-1143	M10	1.5 mm	25 mm	4.8 mm	2.4 mm	5 mm	5	$9.30	Add to Order
Rev. 04-23, 11-22, 08-22, 06-22
