Steel Extended Tip Half Dog Set Screws
| Alloy Steel Half Dog Extended Tip Set Screw, Rockwell C45, ASME B18.3, ASTM F912 |
||||||||
| Part # | Threads | Overall Length | Tip Dia. | Tip Length | Drive Size | Pkg Qty | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| SSS-892 | 4-40 | 1/8" | 0.075" | 0.03" | 0.050" | 25 | $14.57 | Add to Order |
| SSS-893 | 4-40 | 3/16" | 0.075" | 0.03" | 0.050" | 25 | $17.58 | Add to Order |
| SSS-894 | 4-40 | 1/4" | 0.075" | 0.03" | 0.050" | 50 | $16.65 | Add to Order |
| SSS-895 | 5-40 | 1/8" | 0.083" | 0.033" | 1/16" | 25 | $17.64 | Add to Order |
| SSS-896 | 5-40 | 3/16" | 0.083" | 0.033" | 1/16" | 25 | $18.96 | Add to Order |
| SSS-897 | 5-40 | 1/4" | 0.083" | 0.033" | 1/16" | 25 | $19.07 | Add to Order |
| SSS-898 | 5-40 | 3/8" | 0.083" | 0.033" | 1/16" | 25 | $19.40 | Add to Order |
| SSS-899 | 6-32 | 1/8" | 0.092" | 0.038" | 1/16" | 25 | $18.73 | Add to Order |
| SSS-900 | 6-32 | 3/16" | 0.092" | 0.038" | 1/16" | 25 | $15.39 | Add to Order |
| SSS-901 | 6-32 | 1/4" | 0.092" | 0.038" | 1/16" | 50 | $18.59 | Add to Order |
| SSS-902 | 6-32 | 3/8" | 0.092" | 0.038" | 1/16" | 50 | $18.23 | Add to Order |
| SSS-903 | 8-32 | 1/8" | 0.109" | 0.043" | 5/64" | 25 | $20.58 | Add to Order |
| SSS-904 | 8-32 | 3/16" | 0.109" | 0.043" | 5/64" | 50 | $10.67 | Add to Order |
| SSS-905 | 8-32 | 1/4" | 0.109" | 0.043" | 5/64" | 50 | $19.64 | Add to Order |
| SSS-906 | 8-32 | 5/16" | 0.109" | 0.043" | 5/64" | 50 | $21.90 | Add to Order |
| SSS-907 | 8-32 | 3/8" | 0.109" | 0.043" | 5/64" | 100 | $25.10 | Add to Order |
| SSS-908 | 8-32 | 1/2" | 0.109" | 0.043" | 5/64" | 50 | $19.89 | Add to Order |
| SSS-909 | 10-24 | 3/16" | 0.127" | 0.049" | 3/32" | 50 | $16.80 | Add to Order |
| SSS-910 | 10-24 | 1/4" | 0.127" | 0.049" | 3/32" | 100 | $18.82 | Add to Order |
| SSS-911 | 10-24 | 5/16" | 0.127" | 0.049" | 3/32" | 100 | $21.27 | Add to Order |
| SSS-912 | 10-24 | 3/8" | 0.127" | 0.049" | 3/32" | 50 | $21.00 | Add to Order |
| SSS-12661 | 10-24 | 1/2" | 0.127" | 0.049" | 3/32" | 50 | $23.37 | Add to Order |
| SSS-913 | 10-32 | 3/16" | 0.127" | 0.049" | 3/32" | 50 | $20.27 | Add to Order |
| SSS-914 | 10-32 | 1/4" | 0.127" | 0.049" | 3/32" | 100 | $30.49 | Add to Order |
| SSS-915 | 10-32 | 3/8" | 0.127" | 0.049" | 3/32" | 50 | $19.87 | Add to Order |
| SSS-916 | 10-32 | 1/2" | 0.127" | 0.049" | 3/32" | 50 | $20.43 | Add to Order |
| SSS-917 | 10-32 | 5/8" | 0.127" | 0.049" | 3/32" | 25 | $18.23 | Add to Order |
| SSS-918 | 10-32 | 3/4" | 0.127" | 0.049" | 3/32" | 25 | $20.14 | Add to Order |
| SSS-919 | 10-32 | 1" | 0.127" | 0.049" | 3/32" | 10 | $11.61 | Add to Order |
| SSS-920 | 1/4"-20 | 1/4" | 0.156" | 0.067" | 1/8" | 100 | $24.68 | Add to Order |
| SSS-921 | 1/4"-20 | 5/16" | 0.156" | 0.067" | 1/8" | 100 | $25.10 | Add to Order |
| SSS-922 | 1/4"-20 | 3/8" | 0.156" | 0.067" | 1/8" | 100 | $27.07 | Add to Order |
| SSS-923 | 1/4"-20 | 1/2" | 0.156" | 0.067" | 1/8" | 100 | $33.47 | Add to Order |
| SSS-924 | 1/4"-20 | 5/8" | 0.156" | 0.067" | 1/8" | 25 | $15.81 | Add to Order |
| SSS-925 | 1/4"-20 | 3/4" | 0.156" | 0.067" | 1/8" | 25 | $16.99 | Add to Order |
| SSS-926 | 1/4"-20 | 1" | 0.156" | 0.067" | 1/8" | 25 | $22.55 | Add to Order |
| SSS-927 | 1/4"-20 | 1 1/4" | 0.156" | 0.067" | 1/8" | 10 | $16.09 | Add to Order |
| SSS-928 | 1/4"-20 | 1 1/2" | 0.156" | 0.067" | 1/8" | 10 | $17.89 | Add to Order |
| SSS-929 | 1/4"-28 | 1/4" | 0.156" | 0.067" | 1/8" | 50 | $19.78 | Add to Order |
| SSS-930 | 1/4"-28 | 5/16" | 0.156" | 0.067" | 1/8" | 50 | $15.12 | Add to Order |
| SSS-931 | 1/4"-28 | 3/8" | 0.156" | 0.067" | 1/8" | 50 | $17.45 | Add to Order |
| SSS-932 | 1/4"-28 | 1/2" | 0.156" | 0.067" | 1/8" | 25 | $19.61 | Add to Order |
| SSS-933 | 1/4"-28 | 3/4" | 0.156" | 0.067" | 1/8" | 25 | $18.63 | Add to Order |
| SSS-934 | 5/16"-18 | 1/4" | 0.203" | 0.082" | 5/32" | 50 | $26.00 | Add to Order |
| SSS-935 | 5/16"-18 | 5/16" | 0.203" | 0.082" | 5/32" | 50 | $21.59 | Add to Order |
| SSS-936 | 5/16"-18 | 3/8" | 0.203" | 0.082" | 5/32" | 50 | $19.64 | Add to Order |
| SSS-937 | 5/16"-18 | 1/2" | 0.203" | 0.082" | 5/32" | 25 | $12.35 | Add to Order |
| SSS-938 | 5/16"-18 | 5/8" | 0.203" | 0.082" | 5/32" | 25 | $17.12 | Add to Order |
| SSS-939 | 5/16"-18 | 3/4" | 0.203" | 0.082" | 5/32" | 25 | $17.54 | Add to Order |
| SSS-940 | 5/16"-18 | 1" | 0.203" | 0.082" | 5/32" | 25 | $18.69 | Add to Order |
| SSS-941 | 5/16"-18 | 1 1/2" | 0.203" | 0.082" | 5/32" | 5 | $19.57 | Add to Order |
| SSS-942 | 5/16"-18 | 2" | 0.203" | 0.082" | 5/32" | 5 | $16.74 | Add to Order |
| SSS-943 | 5/16"-24 | 3/8" | 0.203" | 0.082" | 5/32" | 25 | $12.75 | Add to Order |
| SSS-944 | 5/16"-24 | 1/2" | 0.203" | 0.082" | 5/32" | 25 | $14.01 | Add to Order |
| SSS-945 | 5/16"-24 | 3/4" | 0.203" | 0.082" | 5/32" | 25 | $23.71 | Add to Order |
| SSS-2662B | 5/16"-24 | 1" | 0.203" | 0.082" | 5/32" | 10 | $17.35 | Add to Order |
| SSS-946 | 5/16"-24 | 1 1/4" | 0.203" | 0.082" | 5/32" | 10 | $18.75 | Add to Order |
| SSS-947 | 3/8"-16 | 3/8" | 0.25" | 0.099" | 3/16" | 25 | $10.58 | Add to Order |
| SSS-948 | 3/8"-16 | 1/2" | 0.25" | 0.099" | 3/16" | 25 | $15.46 | Add to Order |
| SSS-949 | 3/8"-16 | 5/8" | 0.25" | 0.099" | 3/16" | 25 | $15.31 | Add to Order |
| SSS-950 | 3/8"-16 | 3/4" | 0.25" | 0.099" | 3/16" | 25 | $17.43 | Add to Order |
| SSS-951 | 3/8"-16 | 1" | 0.25" | 0.099" | 3/16" | 25 | $22.41 | Add to Order |
| SSS-952 | 3/8"-16 | 1 1/4" | 0.25" | 0.099" | 3/16" | 25 | $27.93 | Add to Order |
| SSS-953 | 3/8"-16 | 1 1/2" | 0.25" | 0.099" | 3/16" | 5 | $12.52 | Add to Order |
| SSS-954 | 3/8"-24 | 1/2" | 0.25" | 0.099" | 3/16" | 25 | $20.56 | Add to Order |
| SSS-955 | 3/8"-24 | 5/8" | 0.25" | 0.099" | 3/16" | 10 | $14.95 | Add to Order |
| SSS-956 | 3/8"-24 | 3/4" | 0.25" | 0.099" | 3/16" | 10 | $13.59 | Add to Order |
| SSS-957 | 3/8"-24 | 1" | 0.25" | 0.099" | 3/16" | 10 | $18.12 | Add to Order |
| SSS-958 | 1/2"-13 | 1/2" | 0.343" | 0.13" | 1/4" | 10 | $15.26 | Add to Order |
| SSS-959 | 1/2"-13 | 5/8" | 0.343" | 0.13" | 1/4" | 10 | $16.17 | Add to Order |
| SSS-960 | 1/2"-13 | 3/4" | 0.343" | 0.13" | 1/4" | 10 | $18.96 | Add to Order |
| SSS-961 | 1/2"-13 | 1" | 0.343" | 0.13" | 1/4" | 10 | $22.34 | Add to Order |
| SSS-962 | 1/2"-13 | 1 1/4" | 0.343" | 0.13" | 1/4" | 10 | $24.65 | Add to Order |
| SSS-963 | 1/2"-13 | 1 1/2" | 0.343" | 0.13" | 1/4" | 5 | $19.13 | Add to Order |
| SSS-964 | 1/2"-13 | 2" | 0.343" | 0.13" | 1/4" | 5 | $37.57 | Add to Order |
| SSS-965 | 1/2"-13 | 2 1/2" | 0.343" | 0.13" | 1/4" | 5 | $33.56 | Add to Order |
| SSS-966 | 1/2"-20 | 1/2" | 0.343" | 0.13" | 1/4" | 5 | $16.17 | Add to Order |
| SSS-967 | 1/2"-20 | 3/4" | 0.343" | 0.13" | 1/4" | 5 | $15.88 | Add to Order |
| SSS-968 | 1/2"-20 | 1" | 0.343" | 0.13" | 1/4" | 5 | $20.48 | Add to Order |
| SSS-969 | 1/2"-20 | 2" | 0.343" | 0.13" | 1/4" | 1 | $9.28 | Add to Order |
| SSS-970 | 1/2"-20 | 2 1/2" | 0.343" | 0.13" | 1/4" | 1 | $10.58 | Add to Order |
| SSS-971 | 5/8"-11 | 1" | 0.468" | 0.164" | 5/16" | 10 | $33.50 | Add to Order |
| SSS-972 | 5/8"-11 | 1 1/2" | 0.468" | 0.164" | 5/16" | 1 | $10.12 | Add to Order |
| SSS-973 | 5/8"-11 | 2" | 0.468" | 0.164" | 5/16" | 1 | $10.19 | Add to Order |
| SSS-974 | 5/8"-18 | 1" | 0.468" | 0.164" | 5/16" | 1 | $7.77 | Add to Order |
| SSS-975 | 5/8"-18 | 1 1/2" | 0.468" | 0.164" | 5/16" | 1 | $10.37 | Add to Order |
| Rev. 10-23, 04-23, 11-22, 03-22 | ||||||||
