Metric Steel Extended Tip Half Dog Set Screws
| Metric Alloy Steel Half Dog Extended Tip Set Screw, Rockwell C45, DIN 915, ISO 4028 |
|||||||||
| Part # | Threads (mm) | Pitch | Tip Dia | Overall Length (mm) | Tip Length (mm) | Drive Size (mm) | Pkg. Qty | Pkg Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| SSS-12663 | M3 | 0.5 mm | 2 | 4 | 1 | 1.5 | 100 | $13.38 | Add to Order |
| SSS-12664 | M3 | 0.5 mm | 2 | 5 | 1 | 1.5 | 100 | $14.22 | Add to Order |
| SSS-12665 | M3 | 0.5 mm | 2 | 8 | 1.75 | 1.5 | 100 | $15.46 | Add to Order |
| SSS-12666 | M4 | 0.7 mm | 2.5 | 5 | 1.25 | 2 | 100 | $13.29 | Add to Order |
| SSS-12667 | M4 | 0.7 mm | 2.5 | 6 | 1.25 | 2 | 100 | $12.68 | Add to Order |
| SSS-12668 | M4 | 0.7 mm | 2.5 | 8 | 2.25 | 2 | 100 | $16.30 | Add to Order |
| SSS-2669 | M4 | 0.7 mm | 2.5 | 10 | 2.25 | 2 | 100 | $19.43 | Add to Order |
| SSS-2670 | M4 | 0.7 mm | 2.5 | 12 | 2.25 | 2 | 100 | $19.89 | Add to Order |
| SSS-2671 | M5 | 0.8 mm | 3.5 | 6 | 1.5 | 2.5 | 100 | $15.18 | Add to Order |
| SSS-2672 | M5 | 0.8 mm | 3.5 | 8 | 2.75 | 2.5 | 100 | $13.73 | Add to Order |
| SSS-2673 | M5 | 0.8 mm | 3.5 | 12 | 2.75 | 2.5 | 100 | $16.28 | Add to Order |
| SSS-1389 | M6 | 1 mm | 4 | 6 | 1.75 | 3 | 25 | $9.45 | Add to Order |
| SSS-1390 | M6 | 1 mm | 4 | 8 | 1.75 | 3 | 50 | $16.38 | Add to Order |
| SSS-1391 | M6 | 1 mm | 4 | 10 | 3.25 | 3 | 50 | $16.80 | Add to Order |
| SSS-1392 | M6 | 1 mm | 4 | 12 | 3.25 | 3 | 50 | $18.90 | Add to Order |
| SSS-1393 | M6 | 1 mm | 4 | 16 | 3.25 | 3 | 50 | $28.79 | Add to Order |
| SSS-2674 | M6 | 1 mm | 4 | 18 | 3.25 | 3 | 25 | $21.42 | Add to Order |
| SSS-1394 | M6 | 1 mm | 4 | 20 | 3.25 | 3 | 25 | $15.12 | Add to Order |
| SSS-1395 | M6 | 1 mm | 4 | 25 | 3.25 | 3 | 25 | $15.96 | Add to Order |
| SSS-1396 | M6 | 1 mm | 4 | 30 | 3.25 | 3 | 25 | $18.82 | Add to Order |
| SSS-1397 | M6 | 1 mm | 4 | 35 | 3.25 | 3 | 25 | $29.40 | Add to Order |
| SSS-2675 | M6 | 1 mm | 4 | 50 | 3.25 | 3 | 10 | $18.04 | Add to Order |
| SSS-1398 | M8 | 1.25 mm | 5.5 | 10 | 2.25 | 4 | 25 | $10.40 | Add to Order |
| SSS-1399 | M8 | 1.25 mm | 5.5 | 12 | 4.3 | 4 | 50 | $23.31 | Add to Order |
| SSS-1400 | M8 | 1.25 mm | 5.5 | 16 | 4.3 | 4 | 25 | $23.10 | Add to Order |
| SSS-1401 | M8 | 1.25 mm | 5.5 | 20 | 4.3 | 4 | 25 | $25.20 | Add to Order |
| SSS-1402 | M8 | 1.25 mm | 5.5 | 25 | 4.3 | 4 | 25 | $27.17 | Add to Order |
| SSS-1403 | M8 | 1.25 mm | 5.5 | 30 | 4.3 | 4 | 25 | $33.56 | Add to Order |
| SSS-1404 | M8 | 1.25 mm | 5.5 | 40 | 4.3 | 4 | 10 | $20.16 | Add to Order |
| SSS-1405 | M8 | 1.25 mm | 5.5 | 50 | 4.3 | 4 | 10 | $22.68 | Add to Order |
| SSS-1406 | M10 | 1.5 mm | 7 | 12 | 2.75 | 5 | 25 | $18.06 | Add to Order |
| SSS-1407 | M10 | 1.5 mm | 7 | 16 | 5.3 | 5 | 25 | $27.30 | Add to Order |
| SSS-1408 | M10 | 1.5 mm | 7 | 20 | 5.3 | 5 | 25 | $37.80 | Add to Order |
| SSS-1409 | M10 | 1.5 mm | 7 | 25 | 5.3 | 5 | 25 | $39.90 | Add to Order |
| SSS-1410 | M10 | 1.5 mm | 7 | 30 | 5.3 | 5 | 10 | $20.58 | Add to Order |
| SSS-1411 | M10 | 1.5 mm | 7 | 35 | 5.3 | 5 | 10 | $33.60 | Add to Order |
| SSS-1412 | M10 | 1.5 mm | 7 | 40 | 5.3 | 5 | 10 | $25.14 | Add to Order |
| SSS-1413 | M10 | 1.5 mm | 7 | 50 | 5.3 | 5 | 10 | $48.68 | Add to Order |
| SSS-1414 | M10 | 1.5 mm | 7 | 60 | 5.3 | 5 | 5 | $25.02 | Add to Order |
| SSS-1415 | M12 | 1.75 mm | 8.5 | 12 | 3.25 | 6 | 10 | $10.92 | Add to Order |
| SSS-1416 | M12 | 1.75 mm | 8.5 | 16 | 3.25 | 6 | 25 | $32.93 | Add to Order |
| SSS-1417 | M12 | 1.75 mm | 8.5 | 20 | 6.3 | 6 | 10 | $16.80 | Add to Order |
| SSS-1418 | M12 | 1.75 mm | 8.5 | 25 | 6.3 | 6 | 10 | $20.77 | Add to Order |
| SSS-1490 | M12 | 1.75 mm | 8.5 | 30 | 6.3 | 6 | 10 | $37.86 | Add to Order |
| SSS-1420 | M12 | 1.75 mm | 8.5 | 35 | 6.3 | 6 | 10 | $33.60 | Add to Order |
| SSS-1421 | M12 | 1.75 mm | 8.5 | 40 | 6.3 | 6 | 10 | $55.44 | Add to Order |
| SSS-1422 | M12 | 1.75 mm | 8.5 | 45 | 6.3 | 6 | 5 | $26.04 | Add to Order |
| SSS-1423 | M12 | 1.75 mm | 8.5 | 50 | 6.3 | 6 | 5 | $33.29 | Add to Order |
| SSS-1424 | M12 | 1.75 mm | 8.5 | 60 | 6.3 | 6 | 5 | $33.37 | Add to Order |
| Rev. 01-24, 04-23, 11-22, 03-22 | |||||||||
