316 Stainless Steel Metric Cup Point Set Screws
| 316 Stainless Steel Cup Point Set Screws, Rockwell B80 DIN 916, ISO 4029 | |||||||
| Part # | Thread Size | Pitch (mm) | Overall Length (mm) | Drive Size (mm) | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| SSS-12517 | M2 | 0.4 mm | 3 | 0.9 | 10 | $24.95 | Add to Order |
| SSS-12518 | M2 | 0.4 mm | 4 | 0.9 | 10 | $20.94 | Add to Order |
| SSS-2983 | M2 | 0.4 mm | 5 | 0.9 | 10 | $28.12 | Add to Order |
| SSS-2984 | M2 | 0.4 mm | 6 | 0.9 | 10 | $31.14 | Add to Order |
| SSS-2985 | M2.5 | 0.45 mm | 3 | 1.3 | 50 | $19.97 | Add to Order |
| SSS-2986 | M2.5 | 0.45 mm | 4 | 1.3 | 50 | $34.86 | Add to Order |
| SSS-2987 | M2.5 | 0.45 mm | 5 | 1.3 | 50 | $23.71 | Add to Order |
| SSS-12519 | M3 | 0.5 mm | 3 | 1.5 | 50 | $17.70 | Add to Order |
| SSS-12520 | M3 | 0.5 mm | 4 | 1.5 | 50 | $19.95 | Add to Order |
| SSS-12521 | M3 | 0.5 mm | 5 | 1.5 | 25 | $10.16 | Add to Order |
| SSS-12522 | M3 | 0.5 mm | 6 | 1.5 | 25 | $10.10 | Add to Order |
| SSS-12523 | M3 | 0.5 mm | 8 | 1.5 | 25 | $11.24 | Add to Order |
| SSS-12524 | M3 | 0.5 mm | 10 | 1.5 | 25 | $30.01 | Add to Order |
| SSS-12525 | M3 | 0.5 mm | 12 | 1.5 | 25 | $24.65 | Add to Order |
| SSS-12526 | M3 | 0.5 mm | 16 | 1.5 | 10 | $13.99 | Add to Order |
| SSS-12527 | M4 | 0.7 mm | 4 | 2 | 50 | $19.95 | Add to Order |
| SSS-12528 | M4 | 0.7 mm | 5 | 2 | 50 | $20.94 | Add to Order |
| SSS-12529 | M4 | 0.7 mm | 6 | 2 | 50 | $21.00 | Add to Order |
| SSS-12530 | M4 | 0.7 mm | 8 | 2 | 25 | $11.03 | Add to Order |
| SSS-12531 | M4 | 0.7 mm | 10 | 2 | 25 | $11.42 | Add to Order |
| SSS-12532 | M4 | 0.7 mm | 12 | 2 | 25 | $29.99 | Add to Order |
| SSS-12533 | M4 | 0.7 mm | 16 | 2 | 10 | $13.00 | Add to Order |
| SSS-12534 | M4 | 0.7 mm | 20 | 2 | 10 | $16.23 | Add to Order |
| SSS-12535 | M4 | 0.7 mm | 25 | 2 | 10 | $18.00 | Add to Order |
| SSS-2988 | M4 | 0.7 mm | 30 | 2 | 5 | $11.21 | Add to Order |
| SSS-12536 | M5 | 0.8 mm | 5 | 2.5 | 50 | $22.47 | Add to Order |
| SSS-12537 | M5 | 0.8 mm | 6 | 2.5 | 25 | $12.75 | Add to Order |
| SSS-12538 | M5 | 0.8 mm | 8 | 2.5 | 25 | $12.33 | Add to Order |
| SSS-12539 | M5 | 0.8 mm | 10 | 2.5 | 25 | $13.21 | Add to Order |
| SSS-12540 | M5 | 0.8 mm | 12 | 2.5 | 25 | $27.49 | Add to Order |
| SSS-12541 | M5 | 0.8 mm | 16 | 2.5 | 25 | $17.72 | Add to Order |
| SSS-12542 | M5 | 0.8 mm | 20 | 2.5 | 10 | $13.00 | Add to Order |
| SSS-12543 | M5 | 0.8 mm | 25 | 2.5 | 10 | $17.49 | Add to Order |
| SSS-2989 | M5 | 0.8 mm | 30 | 2.5 | 10 | $34.31 | Add to Order |
| SSS-2990 | M5 | 0.8 mm | 40 | 2.5 | 10 | $32.07 | Add to Order |
| SSS-12544 | M6 | 1 mm | 6 | 3 | 25 | $11.40 | Add to Order |
| SSS-12545 | M6 | 1 mm | 8 | 3 | 25 | $12.85 | Add to Order |
| SSS-12546 | M6 | 1 mm | 10 | 3 | 25 | $13.71 | Add to Order |
| SSS-12547 | M6 | 1 mm | 12 | 3 | 25 | $16.00 | Add to Order |
| SSS-12548 | M6 | 1 mm | 16 | 3 | 10 | $17.01 | Add to Order |
| SSS-12549 | M6 | 1 mm | 20 | 3 | 10 | $10.65 | Add to Order |
| SSS-12550 | M6 | 1 mm | 25 | 3 | 10 | $19.01 | Add to Order |
| SSS-12551 | M6 | 1 mm | 30 | 3 | 10 | $26.02 | Add to Order |
| SSS-12552 | M8 | 1.25 mm | 8 | 4 | 25 | $15.88 | Add to Order |
| SSS-12553 | M8 | 1.25 mm | 10 | 4 | 25 | $20.45 | Add to Order |
| SSS-12554 | M8 | 1.25 mm | 12 | 4 | 25 | $23.75 | Add to Order |
| SSS-12555 | M8 | 1.25 mm | 16 | 4 | 10 | $12.75 | Add to Order |
| SSS-12556 | M8 | 1.25 mm | 20 | 4 | 10 | $15.67 | Add to Order |
| SSS-12557 | M8 | 1.25 mm | 25 | 4 | 10 | $20.08 | Add to Order |
| SSS-12558 | M8 | 1.25 mm | 30 | 4 | 10 | $23.18 | Add to Order |
| SSS-12559 | M8 | 1.25 mm | 40 | 4 | 5 | $23.52 | Add to Order |
| SSS-2991 | M8 | 1.25 mm | 50 | 4 | 1 | $8.53 | Add to Order |
| SSS-12560 | M10 | 1.5 mm | 10 | 5 | 10 | $22.01 | Add to Order |
| SSS-12561 | M10 | 1.5 mm | 12 | 5 | 10 | $23.00 | Add to Order |
| SSS-2992 | M10 | 1.5 mm | 16 | 5 | 5 | $18.23 | Add to Order |
| SSS-12562 | M10 | 1.5 mm | 20 | 5 | 5 | $18.00 | Add to Order |
| SSS-12563 | M10 | 1.5 mm | 25 | 5 | 1 | $4.49 | Add to Order |
| SSS-2564 | M10 | 1.5 mm | 30 | 5 | 1 | $6.62 | Add to Order |
| SSS-12565 | M10 | 1.5 mm | 40 | 5 | 1 | $8.51 | Add to Order |
| SSS-2993 | M12 | 1.75 mm | 12 | 6 | 5 | $28.56 | Add to Order |
| SSS-2994 | M12 | 1.75 mm | 16 | 6 | 5 | $28.16 | Add to Order |
| SSS-2995 | M12 | 1.75 mm | 20 | 6 | 1 | $5.88 | Add to Order |
| SSS-2996 | M12 | 1.75 mm | 25 | 6 | 1 | $6.51 | Add to Order |
| SSS-2997 | M12 | 1.75 mm | 30 | 6 | 1 | $7.75 | Add to Order |
| SSS-2998 | M12 | 1.75 mm | 40 | 6 | 1 | $17.41 | Add to Order |
| SSS-2999 | M12 | 1.75 mm | 50 | 6 | 1 | $23.90 | Add to Order |
| Rev. 04-23, 11-22, 03-22 | |||||||
