18-8 Stainless Steel Metric Cup Point Set Screws
| Metric 18-8 Stainless Steel Cup Point Set Screws, Rockwell B80, DIN 916, ISO 4029 |
|||||||
| Part # | Thread Size | Pitch (mm) | Overall Length (mm) | Drive Size (mm) | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| SSS-2935 | M1.6 | 0.35 mm | 2.5 | 0.7 | 5 | $19.93 | Add to Order |
| SSS-1934 | M1.6 | 0.35 mm | 3 | 0.7 | 10 | $20.77 | Add to Order |
| SSS-1935 | M1.6 | 0.35 mm | 4 | 0.7 | 10 | $18.69 | Add to Order |
| SSS-1936 | M1.6 | 0.35 mm | 5 | 0.7 | 10 | $25.03 | Add to Order |
| SSS-2936 | M1.6 | 0.35 mm | 6 | 0.7 | 10 | $11.36 | Add to Order |
| SSS-2937 | M2 | 0.4 mm | 2.5 | 0.9 | 25 | $16.80 | Add to Order |
| SSS-1937 | M2 | 0.4 mm | 3 | 0.9 | 25 | $12.47 | Add to Order |
| SSS-1938 | M2 | 0.4 mm | 4 | 0.9 | 25 | $14.49 | Add to Order |
| SSS-1939 | M2 | 0.4 mm | 5 | 0.9 | 25 | $17.79 | Add to Order |
| SSS-1940 | M2 | 0.4 mm | 6 | 0.9 | 25 | $19.49 | Add to Order |
| SSS-1941 | M2 | 0.4 mm | 8 | 0.9 | 25 | $23.06 | Add to Order |
| SSS-1942 | M2 | 0.4 mm | 10 | 0.9 | 10 | $13.61 | Add to Order |
| SSS-1943 | M2.5 | 0.45 mm | 3 | 1.3 | 50 | $20.83 | Add to Order |
| SSS-1944 | M2.5 | 0.45 mm | 4 | 1.3 | 50 | $20.10 | Add to Order |
| SSS-1945 | M2.5 | 0.45 mm | 5 | 1.3 | 50 | $24.59 | Add to Order |
| SSS-1946 | M2.5 | 0.45 mm | 6 | 1.3 | 25 | $20.43 | Add to Order |
| SSS-1947 | M2.5 | 0.45 mm | 8 | 1.3 | 25 | $16.40 | Add to Order |
| SSS-1948 | M2.5 | 0.45 mm | 10 | 1.3 | 10 | $10.63 | Add to Order |
| SSS-1949 | M2.5 | 0.45 mm | 12 | 1.3 | 10 | $11.49 | Add to Order |
| SSS-1950 | M3 | 0.5 mm | 3 | 1.5 | 100 | $26.73 | Add to Order |
| SSS-1951 | M3 | 0.5 mm | 4 | 1.5 | 100 | $20.54 | Add to Order |
| SSS-1952 | M3 | 0.5 mm | 5 | 1.5 | 100 | $22.72 | Add to Order |
| SSS-1953 | M3 | 0.5 mm | 6 | 1.5 | 50 | $21.50 | Add to Order |
| SSS-1954 | M3 | 0.5 mm | 8 | 1.5 | 100 | $24.36 | Add to Order |
| SSS-1955 | M3 | 0.5 mm | 10 | 1.5 | 100 | $22.74 | Add to Order |
| SSS-1956 | M3 | 0.5 mm | 12 | 1.5 | 50 | $16.02 | Add to Order |
| SSS-1957 | M3 | 0.5 mm | 16 | 1.5 | 100 | $21.06 | Add to Order |
| SSS-1958 | M3 | 0.5 mm | 20 | 1.5 | 25 | $15.65 | Add to Order |
| SSS-1959 | M3 | 0.5 mm | 30 | 1.5 | 10 | $23.44 | Add to Order |
| SSS-1960 | M4 | 0.7 mm | 4 | 2 | 100 | $13.08 | Add to Order |
| SSS-1961 | M4 | 0.7 mm | 5 | 2 | 100 | $12.71 | Add to Order |
| SSS-1962 | M4 | 0.7 mm | 6 | 2 | 100 | $13.21 | Add to Order |
| SSS-1963 | M4 | 0.7 mm | 8 | 2 | 100 | $14.07 | Add to Order |
| SSS-1964 | M4 | 0.7 mm | 10 | 2 | 100 | $19.45 | Add to Order |
| SSS-1965 | M4 | 0.7 mm | 12 | 2 | 50 | $17.05 | Add to Order |
| SSS-1966 | M4 | 0.7 mm | 16 | 2 | 50 | $12.77 | Add to Order |
| SSS-1967 | M4 | 0.7 mm | 20 | 2 | 100 | $16.23 | Add to Order |
| SSS-1968 | M4 | 0.7 mm | 25 | 2 | 100 | $21.65 | Add to Order |
| SSS-1969 | M4 | 0.7 mm | 30 | 2 | 10 | $11.34 | Add to Order |
| SSS-2938 | M4 | 0.7 mm | 35 | 2 | 10 | $15.94 | Add to Order |
| SSS-2939 | M4 | 0.7 mm | 40 | 2 | 10 | $17.91 | Add to Order |
| SSS-1970 | M5 | 0.8 mm | 5 | 2.5 | 100 | $15.54 | Add to Order |
| SSS-1971 | M5 | 0.8 mm | 6 | 2.5 | 100 | $16.61 | Add to Order |
| SSS-1972 | M5 | 0.8 mm | 8 | 2.5 | 100 | $15.79 | Add to Order |
| SSS-1973 | M5 | 0.8 mm | 10 | 2.5 | 50 | $10.08 | Add to Order |
| SSS-1974 | M5 | 0.8 mm | 12 | 2.5 | 25 | $8.19 | Add to Order |
| SSS-1975 | M5 | 0.8 mm | 16 | 2.5 | 25 | $6.70 | Add to Order |
| SSS-1976 | M5 | 0.8 mm | 20 | 2.5 | 25 | $22.64 | Add to Order |
| SSS-1977 | M5 | 0.8 mm | 25 | 2.5 | 25 | $13.88 | Add to Order |
| SSS-1978 | M5 | 0.8 mm | 30 | 2.5 | 10 | $10.73 | Add to Order |
| SSS-1979 | M5 | 0.8 mm | 35 | 2.5 | 10 | $13.59 | Add to Order |
| SSS-2000 | M5 | 0.8 mm | 40 | 2.5 | 10 | $19.97 | Add to Order |
| SSS-1981 | M6 | 1 mm | 6 | 3 | 100 | $20.58 | Add to Order |
| SSS-1982 | M6 | 1 mm | 8 | 3 | 50 | $9.85 | Add to Order |
| SSS-1983 | M6 | 1 mm | 10 | 3 | 50 | $12.60 | Add to Order |
| SSS-1984 | M6 | 1 mm | 12 | 3 | 50 | $15.83 | Add to Order |
| SSS-1985 | M6 | 1 mm | 16 | 3 | 25 | $12.58 | Add to Order |
| SSS-1986 | M6 | 1 mm | 20 | 3 | 25 | $14.51 | Add to Order |
| SSS-1987 | M6 | 1 mm | 25 | 3 | 25 | $13.08 | Add to Order |
| SSS-1988 | M6 | 1 mm | 30 | 3 | 10 | $10.35 | Add to Order |
| SSS-1989 | M6 | 1 mm | 35 | 3 | 10 | $15.06 | Add to Order |
| SSS-1990 | M6 | 1 mm | 40 | 3 | 10 | $12.29 | Add to Order |
| SSS-2940 | M6 | 1 mm | 45 | 3 | 5 | $13.23 | Add to Order |
| SSS-1991 | M6 | 1 mm | 50 | 3 | 10 | $12.79 | Add to Order |
| SSS-1992 | M8 | 1.25 | 8 | 4 | 25 | $6.05 | Add to Order |
| SSS-1993 | M8 | 1.25 | 10 | 4 | 50 | $13.46 | Add to Order |
| SSS-1994 | M8 | 1.25 | 12 | 4 | 50 | $28.35 | Add to Order |
| SSS-1995 | M8 | 1.25 | 16 | 4 | 25 | $18.27 | Add to Order |
| SSS-1996 | M8 | 1.25 | 20 | 4 | 10 | $12.60 | Add to Order |
| SSS-1997 | M8 | 1.25 | 25 | 4 | 25 | $31.50 | Add to Order |
| SSS-1998 | M8 | 1.25 | 30 | 4 | 10 | $14.15 | Add to Order |
| SSS-1999 | M8 | 1.25 | 35 | 4 | 10 | $22.37 | Add to Order |
| SSS-2000 | M8 | 1.25 | 40 | 4 | 10 | $19.97 | Add to Order |
| SSS-2941 | M8 | 1.25 | 45 | 4 | 5 | $17.91 | Add to Order |
| SSS-2001 | M8 | 1.25 | 50 | 4 | 10 | $14.60 | Add to Order |
| SSS-2002 | M10 | 1.5 mm | 10 | 5 | 25 | $15.54 | Add to Order |
| SSS-2003 | M10 | 1.5 mm | 12 | 5 | 25 | $14.32 | Add to Order |
| SSS-2004 | M10 | 1.5 mm | 16 | 5 | 10 | $10.94 | Add to Order |
| SSS-2005 | M10 | 1.5 mm | 20 | 5 | 10 | $19.36 | Add to Order |
| SSS-2006 | M10 | 1.5 mm | 25 | 5 | 25 | $63.00 | Add to Order |
| SSS-2007 | M10 | 1.5 mm | 30 | 5 | 10 | $15.62 | Add to Order |
| SSS-2008 | M10 | 1.5 mm | 35 | 5 | 5 | $10.44 | Add to Order |
| SSS-2009 | M10 | 1.5 mm | 40 | 5 | 5 | $16.42 | Add to Order |
| SSS-2942 | M10 | 1.5 mm | 45 | 5 | 5 | $34.08 | Add to Order |
| SSS-2010 | M10 | 1.5 mm | 50 | 5 | 5 | $17.60 | Add to Order |
| SSS-2011 | M12 | 1.75 mm | 12 | 6 | 5 | $11.34 | Add to Order |
| SSS-2012 | M12 | 1.75 mm | 16 | 6 | 10 | $20.03 | Add to Order |
| SSS-2013 | M12 | 1.75 mm | 20 | 6 | 5 | $12.03 | Add to Order |
| SSS-2014 | M12 | 1.75 mm | 25 | 6 | 5 | $18.06 | Add to Order |
| SSS-2015 | M12 | 1.75 mm | 30 | 6 | 5 | $26.25 | Add to Order |
| SSS-2016 | M12 | 1.75 mm | 35 | 6 | 5 | $23.35 | Add to Order |
| SSS-2017 | M12 | 1.75 mm | 40 | 6 | 5 | $22.79 | Add to Order |
| SSS-2943 | M12 | 1.75 mm | 45 | 6 | 1 | $11.84 | Add to Order |
| SSS-2018 | M12 | 1.75 mm | 50 | 6 | 5 | $33.39 | Add to Order |
| SSS-2944 | M12 | 1.75 mm | 60 | 6 | 1 | $15.69 | Add to Order |
| SSS-2945 | M16 | 2 mm | 16 | 8 | 5 | $22.34 | Add to Order |
| SSS-2946 | M16 | 2 mm | 20 | 8 | 1 | $5.29 | Add to Order |
| Rev. 10-23, 04-23, 12-22, 11-22 | |||||||
