18-8 Stainless Steel Pan Head Torx Drive Machine Screws
Machine Screws - Pan Head Torx Drive, Class 2A, fully threaded, Torx drive reduces slipping and improves driving power, round top and flat bearing surface.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| 18-8
Stainless Steel Pan Head Torx Machine Screws FT, 70,000 PSI Tensile , ASME B18.6.3 |
|||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Style | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-10902 | 000-120 | 1/8" | 0.066" | 0.026" | Torx Plus | IP1, T1 | 25 | $30.28 | Add to Order |
| MSS-10903 | 000-120 | 3/16" | 0.066" | 0.026" | Torx Plus | IP1, T1 | 25 | $30.68 | Add to Order |
| MSS-10904 | 000-120 | 1/4" | 0.066" | 0.026" | Torx Plus | IP1, T1 | 25 | $31.10 | Add to Order |
| MSS-10905 | 00-90 | 1/8" | 0.090" | 0.036" | Torx Plus | IP2, T2 | 25 | $28.64 | Add to Order |
| MSS-10906 | 00-90 | 3/16" | 0.090" | 0.036" | Torx Plus | IP2, T2 | 25 | $28.84 | Add to Order |
| MSS-10907 | 00-90 | 1/4" | 0.090" | 0.036" | Torx Plus | IP2, T2 | 25 | $29.04 | Add to Order |
| MSS-1122 | 0-80 | 1/8" | 0.116" | 0.044" | Torx Plus | IP5, T5 | 50 | $18.00 | Add to Order |
| MSS-1123 | 0-80 | 3/16" | 0.116" | 0.044" | Torx Plus | IP5, T5 | 50 | $18.48 | Add to Order |
| MSS-1124 | 0-80 | 1/4" | 0.116" | 0.044" | Torx Plus | IP5, T5 | 50 | $18.58 | Add to Order |
| MSS-9982 | 0-80 | 3/8" | 0.142" | 0.053" | Torx | T5 | 100 | $32.24 | Add to Order |
| MSS-9983 | 2-56 | 1/8" | 0.167" | 0.062" | Torx | T8 | 100 | $28.74 | Add to Order |
| MSS-1125 | 2-56 | 3/16" | 0.167" | 0.063" | Torx Plus | IP7, T7 | 50 | $15.42 | Add to Order |
| MSS-1126 | 2-56 | 1/4" | 0.167" | 0.063" | Torx Plus | IP7, T7 | 50 | $15.90 | Add to Order |
| MSS-6284 | 2-56 | 5/16" | 0.167" | 0.063" | Torx Plus | IP7, T7 | 25 | $19.86 | Add to Order |
| MSS-6285 | 2-56 | 3/8" | 0.167" | 0.063" | Torx Plus | IP7, T7 | 25 | $20.04 | Add to Order |
| MSS-9984 | 2-56 | 1/2" | 0.167" | 0.062" | Torx | T8 | 100 | $30.92 | Add to Order |
| MSS-9985 | 4-40 | 1/8" | 0.219" | 0.080" | Torx | T10 | 100 | $27.54 | Add to Order |
| MSS-6298 | 4-40 | 3/16" | 0.219" | 0.080" | Torx Plus | IP10, T10 | 50 | $27.62 | Add to Order |
| MSS-1094 | 4-40 | 1/4" | 0.219" | 0.080" | Torx Plus | IP10, T10 | 50 | $16.16 | Add to Order |
| MSS-6287 | 4-40 | 5/16" | 0.219" | 0.080" | Torx Plus | IP10, T10 | 50 | $28.30 | Add to Order |
| MSS-1117 | 4-40 | 3/8" | 0.219" | 0.080" | Torx Plus | IP10, T10 | 50 | $15.98 | Add to Order |
| MSS-1115 | 4-40 | 1/2" | 0.219" | 0.080" | Torx Plus | IP10, T10 | 50 | $16.94 | Add to Order |
| MSS-9986 | 4-40 | 5/8" | 0.219" | 0.080" | Torx | T10 | 100 | $55.04 | Add to Order |
| MSS-9987 | 4-40 | 3/4" | 0.270" | 0.097" | Torx | T10 | 100 | $57.40 | Add to Order |
| MSS-9988 | 6-32 | 3/16" | 0.270" | 0.097" | Torx | T15 | 100 | $54.96 | Add to Order |
| MSS-1083 | 6-32 | 1/4" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $20.06 | Add to Order |
| MSS-6276 | 6-32 | 5/16" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $30.38 | Add to Order |
| MSS-1084 | 6-32 | 3/8" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $21.40 | Add to Order |
| MSS-1085 | 6-32 | 1/2" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $22.56 | Add to Order |
| MSS-1086 | 6-32 | 5/8" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $23.72 | Add to Order |
| MSS-1087 | 6-32 | 3/4" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $24.88 | Add to Order |
| MSS-1088 | 6-32 | 1" | 0.270" | 0.097" | Torx Plus | IP15, T15 | 50 | $26.02 | Add to Order |
| MSS-1089 | 8-32 | 1/4" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $23.36 | Add to Order |
| MSS-1090 | 8-32 | 3/8" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $25.18 | Add to Order |
| MSS-1091 | 8-32 | 1/2" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $27.00 | Add to Order |
| MSS-1104 | 8-32 | 5/8" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $28.80 | Add to Order |
| MSS-1093 | 8-32 | 3/4" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $30.62 | Add to Order |
| MSS-1082 | 8-32 | 1" | 0.322" | 0.115" | Torx Plus | IP20, T20 | 50 | $32.42 | Add to Order |
| MSS-1095 | 10-24 | 3/8" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 50 | $30.72 | Add to Order |
| MSS-1096 | 10-24 | 1/2" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 50 | $32.38 | Add to Order |
| MSS-1097 | 10-24 | 3/4" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $18.12 | Add to Order |
| MSS-1098 | 10-24 | 1" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $19.04 | Add to Order |
| MSS-1100 | 10-32 | 1/4" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 50 | $28.76 | Add to Order |
| MSS-1101 | 10-32 | 3/8" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 50 | $30.72 | Add to Order |
| MSS-6289 | 10-32 | 1/2" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $20.46 | Add to Order |
| MSS-1102 | 10-32 | 5/8" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $17.38 | Add to Order |
| MSS-1103 | 10-32 | 3/4" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $18.12 | Add to Order |
| MSS-1099 | 10-32 | 1" | 0.373" | 0.133" | Torx Plus | IP25, T25 | 25 | $18.88 | Add to Order |
| MSS-962 | 1/4"-20 | 1/2" | 0.492" | 0.175" | Torx Plus | IP30, T30 | 25 | $22.38 | Add to Order |
| MSS-1056 | 1/4"-20 | 3/4" | 0.492" | 0.175" | Torx Plus | IP30, T30 | 25 | $24.32 | Add to Order |
| MSS-966 | 1/4"-20 | 1" | 0.492" | 0.175" | Torx Plus | IP30, T30 | 25 | $27.88 | Add to Order |
| MSS-967 | 1/4"-20 | 1 1/2" | 0.492" | 0.175" | Torx Plus | IP30, T30 | 25 | $25.60 | Add to Order |
| MSS-968 | 1/4"-20 | 2" | 0.492" | 0.175" | Torx Plus | IP30, T30 | 25 | $43.68 | Add to Order |
| Rev. 08-23, 11-22, 03-22 | |||||||||
