Polycarbonate Pan Head Phillips Machine Screws
Machine Screws - Pan Head Phillips Drive, Class 2A, fully threaded, 82° bevel under head provides flush surface.
Polycarbonate - Impact resistant, non conductive, does not absorb moisture. Temperature range is -40°/+212°F. Clear.
| Polycarbonate Pan Head Phillips Machine Screws | ||||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Drive Size | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| MSS-7347 | 2-56 | 1/8" | 0.170" | 0.063" | No. 1 | 25 | $26.10 | Add to Order |
| MSS-7348 | 2-56 | 3/16" | 0.170" | 0.063" | No. 1 | 25 | $25.62 | Add to Order |
| MSS-7349 | 2-56 | 1/4" | 0.170" | 0.063" | No. 1 | 25 | $25.49 | Add to Order |
| MSS-7350 | 2-56 | 3/8" | 0.170" | 0.063" | No. 1 | 25 | $26.06 | Add to Order |
| MSS-7351 | 2-56 | 1/2" | 0.170" | 0.063" | No. 1 | 25 | $26.06 | Add to Order |
| MSS-7352 | 4-40 | 3/16" | 0.219" | 0.080" | No. 1 | 50 | $45.82 | Add to Order |
| MSS-4455 | 4-40 | 1/4" | 0.219" | 0.080" | No. 1 | 50 | $48.87 | Add to Order |
| MSS-4453 | 4-40 | 3/8" | 0.219" | 0.080" | No. 1 | 50 | $34.00 | Add to Order |
| MSS-4421 | 4-40 | 1/2" | 0.219" | 0.080" | No. 1 | 25 | $26.63 | Add to Order |
| MSS-7353 | 4-40 | 3/4" | 0.215" | 0.075" | No. 1 | 25 | $49.01 | Add to Order |
| MSS-4422 | 6-32 | 1/4" | 0.270" | 0.097" | No. 2 | 25 | $27.05 | Add to Order |
| MSS-4423 | 6-32 | 3/8" | 0.270" | 0.097" | No. 2 | 25 | $27.05 | Add to Order |
| MSS-4424 | 6-32 | 1/2" | 0.270" | 0.097" | No. 2 | 25 | $27.66 | Add to Order |
| MSS-7354 | 6-32 | 3/4" | 0.263" | 0.092" | No. 1 | 25 | $50.76 | Add to Order |
| MSS-7355 | 6-32 | 1" | 0.263" | 0.092" | No. 2 | 25 | $50.76 | Add to Order |
| MSS-4425 | 8-32 | 1/4" | 0.322" | 0.115" | No. 2 | 25 | $32.72 | Add to Order |
| MSS-4426 | 8-32 | 3/8" | 0.322" | 0.115" | No. 2 | 25 | $28.37 | Add to Order |
| MSS-7356 | 8-32 | 1/2" | 0.320" | 0.110" | No. 2 | 25 | $52.52 | Add to Order |
| MSS-7357 | 8-32 | 3/4" | 0.320" | 0.110" | No. 2 | 25 | $52.52 | Add to Order |
| MSS-7358 | 8-32 | 1" | 0.320" | 0.110" | No. 2 | 25 | $52.52 | Add to Order |
| MSS-4427 | 10-32 | 1/4" | 0.373" | 0.133" | No. 2 | 25 | $28.54 | Add to Order |
| MSS-4428 | 10-32 | 3/8" | 0.373" | 0.133" | No. 2 | 25 | $28.92 | Add to Order |
| MSS-4429 | 10-32 | 1/2" | 0.373" | 0.133" | No. 2 | 25 | $26.08 | Add to Order |
| MSS-4442 | 10-32 | 5/8" | 0.373" | 0.133" | No. 2 | 25 | $29.29 | Add to Order |
| MSS-4431 | 10-32 | 3/4" | 0.373" | 0.133" | No. 2 | 25 | $29.51 | Add to Order |
| MSS-4420 | 10-32 | 1" | 0.373" | 0.133" | No. 2 | 25 | $29.74 | Add to Order |
| MSS-7359 | 1/4"-20 | 3/8" | 0.485" | 0.165" | No. 3 | 10 | $32.91 | Add to Order |
| MSS-7360 | 1/4"-20 | 1/2" | 0.485" | 0.165" | No. 3 | 10 | $32.91 | Add to Order |
| MSS-4433 | 1/4"-20 | 3/4" | 0.505" | 0.180" | No. 3 | 10 | $11.24 | Add to Order |
| MSS-4434 | 1/4"-20 | 1" | 0.505" | 0.180" | No. 3 | 10 | $19.68 | Add to Order |
| MSS-7361 | 1/4"-20 | 1 1/2" | 0.485" | 0.165" | No. 3 | 10 | $32.91 | Add to Order |
| Rev. 08-23, 11-22, 03-22 | ||||||||
