18-8 Stainless Steel Pan Head Phillips Metric Machine Screws
Machine Screws - Pan Head Phillips Drive, Class 6g, DIN 7985, fully threaded, round top and flat bearing surface, used for general applications.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| Metric 18-8 Stainless Steel Pan Head Phillips Machine Screws, DIN 7985, 70000 PSI Tensile |
|||||||||
| Part # | Thread Size (mm) | Pitch (mm) | Length (mm) | Head Dia. (mm) | Head Height. (mm) | Drive Size | Pkg Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| MSS-7051 | M1.6 | 0.35 mm | 2 | 3.2 | 1.4 | No. 0 | 100 | $28.75 | Add to Order |
| MSS-6299 | M1.6 | 0.35 mm | 3 | 3.2 | 1.4 | No. 0 | 100 | $30.62 | Add to Order |
| MSS-6312 | M1.6 | 0.35 mm | 4 | 3.2 | 1.4 | No. 0 | 100 | $31.12 | Add to Order |
| MSS-6313 | M1.6 | 0.35 mm | 5 | 3.2 | 1.4 | No. 0 | 100 | $32.57 | Add to Order |
| MSS-6314 | M1.6 | 0.35 mm | 6 | 3.2 | 1.4 | No. 0 | 100 | $33.16 | Add to Order |
| MSS-6315 | M1.6 | 0.35 mm | 8 | 3.2 | 1.4 | No. 0 | 100 | $34.55 | Add to Order |
| MSS-6316 | M1.6 | 0.35 mm | 10 | 3.2 | 1.4 | No. 0 | 50 | $24.19 | Add to Order |
| MSS-6317 | M1.6 | 0.35 mm | 12 | 3.2 | 1.4 | No. 0 | 50 | $31.08 | Add to Order |
| MSS-7052 | M1.6 | 0.35 mm | 16 | 3.2 | 1.4 | No. 0 | 50 | $25.87 | Add to Order |
| MSS-7053 | M1.6 | 0.35 mm | 20 | 3.2 | 1.4 | No. 0 | 50 | $29.23 | Add to Order |
| MSS-1001 | M2 | 0.4 mm | 3 | 4 | 1.7 | No. 1 | 50 | $27.34 | Add to Order |
| MSS-1002 | M2 | 0.4 mm | 4 | 4 | 1.7 | No. 1 | 100 | $12.62 | Add to Order |
| MSS-1003 | M2 | 0.4 mm | 5 | 4 | 1.7 | No. 1 | 100 | $12.83 | Add to Order |
| MSS-1004 | M2 | 0.4 mm | 6 | 4 | 1.7 | No. 1 | 100 | $13.27 | Add to Order |
| MSS-1005 | M2 | 0.4 mm | 8 | 4 | 1.7 | No. 1 | 100 | $13.57 | Add to Order |
| MSS-1006 | M2 | 0.4 mm | 10 | 4 | 1.7 | No. 1 | 100 | $15.27 | Add to Order |
| MSS-1007 | M2 | 0.4 mm | 12 | 4 | 1.7 | No. 1 | 100 | $16.84 | Add to Order |
| MSS-1008 | M2 | 0.4 mm | 14 | 4 | 1.7 | No. 1 | 100 | $17.30 | Add to Order |
| MSS-3266 | M2 | 0.4 mm | 16 | 4 | 1.7 | No. 1 | 100 | $13.27 | Add to Order |
| MSS-257 | M2 | 0.4 mm | 18 | 4 | 1.7 | No. 1 | 100 | $21.00 | Add to Order |
| MSS-2513 | M2 | 0.4 mm | 20 | 4 | 1.7 | No. 1 | 100 | $21.23 | Add to Order |
| MSS-7054 | M2 | 0.4 mm | 30 | 4.24 | 1.58 | No. 1 | 25 | $24.32 | Add to Order |
| MSS-7055 | M2.5 | 0.45 mm | 3 | 5 | 2.1 | No. 1 | 100 | $15.27 | Add to Order |
| MSS-4508 | M2.5 | 0.45 mm | 4 | 5 | 2.1 | No. 1 | 100 | $9.62 | Add to Order |
| MSS-4509 | M2.5 | 0.45 mm | 5 | 5 | 2.1 | No. 1 | 100 | $9.72 | Add to Order |
| MSS-4510 | M2.5 | 0.45 mm | 6 | 5 | 2.1 | No. 1 | 100 | $9.85 | Add to Order |
| MSS-4511 | M2.5 | 0.45 mm | 8 | 5 | 2.1 | No. 1 | 100 | $9.95 | Add to Order |
| MSS-5533 | M2.5 | 0.45 mm | 10 | 5 | 2.1 | No. 1 | 100 | $10.77 | Add to Order |
| MSS-5534 | M2.5 | 0.45 mm | 12 | 5 | 2.1 | No. 1 | 100 | $10.88 | Add to Order |
| MSS-5535 | M2.5 | 0.45 mm | 14 | 5 | 2.1 | No. 1 | 100 | $10.98 | Add to Order |
| MSS-5536 | M2.5 | 0.45 mm | 16 | 5 | 2.1 | No. 1 | 100 | $12.03 | Add to Order |
| MSS-4516 | M2.5 | 0.45 mm | 20 | 5 | 2.1 | No. 1 | 100 | $14.99 | Add to Order |
| MSS-5544 | M2.5 | 0.45 mm | 25 | 5 | 2.1 | No. 1 | 100 | $14.20 | Add to Order |
| MSS-7056 | M2.5 | 0.45 mm | 30 | 5 | 2.1 | No. 1 | 100 | $22.89 | Add to Order |
| MSS-7057 | M3 | 0.5 mm | 3 | 6 | 2.5 | No. 1 | 100 | $19.47 | Add to Order |
| MSS-5546 | M3 | 0.5 mm | 4 | 6 | 2.5 | No. 1 | 100 | $11.21 | Add to Order |
| MSS-4507 | M3 | 0.5 mm | 5 | 6 | 2.5 | No. 1 | 100 | $11.45 | Add to Order |
| MSS-4520 | M3 | 0.5 mm | 6 | 6 | 2.5 | No. 1 | 100 | $14.76 | Add to Order |
| MSS-5523 | M3 | 0.5 mm | 8 | 6 | 2.5 | No. 1 | 100 | $11.57 | Add to Order |
| MSS-4522 | M3 | 0.5 mm | 10 | 6 | 2.5 | No. 1 | 100 | $13.06 | Add to Order |
| MSS-4523 | M3 | 0.5 mm | 12 | 6 | 2.5 | No. 1 | 100 | $13.97 | Add to Order |
| MSS-6318 | M3 | 0.5 mm | 14 | 6 | 2.5 | No. 1 | 100 | $22.70 | Add to Order |
| MSS-4524 | M3 | 0.5 mm | 16 | 6 | 2.5 | No. 1 | 100 | $15.96 | Add to Order |
| MSS-6319 | M3 | 0.5 mm | 18 | 6 | 2.5 | No. 1 | 100 | $23.69 | Add to Order |
| MSS-4525 | M3 | 0.5 mm | 20 | 6 | 2.5 | No. 1 | 100 | $17.41 | Add to Order |
| MSS-4526 | M3 | 0.5 mm | 25 | 6 | 2.5 | No. 1 | 100 | $18.54 | Add to Order |
| MSS-4527 | M3 | 0.5 mm | 30 | 6 | 2.5 | No. 1 | 100 | $19.70 | Add to Order |
| MSS-4528 | M3 | 0.5 mm | 35 | 6 | 2.5 | No. 1 | 100 | $24.97 | Add to Order |
| MSS-5551 | M3 | 0.5 mm | 40 | 6 | 2.5 | No. 1 | 100 | $27.49 | Add to Order |
| MSS-6320 | M3 | 0.5 mm | 45 | 6 | 2.5 | No. 1 | 100 | $33.18 | Add to Order |
| MSS-5550 | M3 | 0.5 mm | 50 | 6 | 2.5 | No. 1 | 50 | $15.92 | Add to Order |
| MSS-7058 | M3 | 0.5 mm | 60 | 6 | 2.5 | No. 1 | 50 | $25.20 | Add to Order |
| MSS-7059 | M3.5 | 0.6 mm | 5 | 7 | 2.8 | No. 2 | 100 | $20.73 | Add to Order |
| MSS-7060 | M3.5 | 0.6 mm | 6 | 7 | 2.8 | No. 2 | 100 | $25.77 | Add to Order |
| MSS-7061 | M3.5 | 0.6 mm | 8 | 7 | 2.8 | No. 2 | 100 | $26.12 | Add to Order |
| MSS-7062 | M3.5 | 0.6 mm | 10 | 7 | 2.8 | No. 2 | 100 | $26.57 | Add to Order |
| MSS-7063 | M3.5 | 0.6 mm | 12 | 7 | 2.8 | No. 2 | 100 | $27.64 | Add to Order |
| MSS-7064 | M3.5 | 0.6 mm | 16 | 7 | 2.8 | No. 2 | 100 | $31.58 | Add to Order |
| MSS-7065 | M3.5 | 0.6 mm | 20 | 7 | 2.8 | No. 2 | 50 | $20.71 | Add to Order |
| MSS-7066 | M3.5 | 0.6 mm | 25 | 7 | 2.8 | No. 2 | 50 | $24.19 | Add to Order |
| MSS-7067 | M4 | 0.7 mm | 4 | 8 | 3.2 | No. 2 | 100 | $30.91 | Add to Order |
| MSS-5549 | M4 | 0.7 mm | 5 | 8 | 3.2 | No. 2 | 100 | $18.10 | Add to Order |
| MSS-4985 | M4 | 0.7 mm | 6 | 8 | 3.2 | No. 2 | 100 | $23.08 | Add to Order |
| MSS-4986 | M4 | 0.7 mm | 8 | 8 | 3.2 | No. 2 | 100 | $18.67 | Add to Order |
| MSS-4987 | M4 | 0.7 mm | 10 | 8 | 3.2 | No. 2 | 100 | $22.45 | Add to Order |
| MSS-4988 | M4 | 0.7 mm | 12 | 8 | 3.2 | No. 2 | 100 | $22.55 | Add to Order |
| MSS-7068 | M4 | 0.7 mm | 14 | 8 | 3.2 | No. 2 | 100 | $24.34 | Add to Order |
| MSS-5548 | M4 | 0.7 mm | 16 | 8 | 3.2 | No. 2 | 100 | $22.79 | Add to Order |
| MSS-7069 | M4 | 0.7 mm | 18 | 8 | 3.2 | No. 2 | 100 | $27.20 | Add to Order |
| MSS-5547 | M4 | 0.7 mm | 20 | 8 | 3.2 | No. 2 | 100 | $28.43 | Add to Order |
| MSS-5538 | M4 | 0.7 mm | 25 | 8 | 3.2 | No. 2 | 100 | $28.75 | Add to Order |
| MSS-5545 | M4 | 0.7 mm | 30 | 8 | 3.2 | No. 2 | 100 | $32.97 | Add to Order |
| MSS-5553 | M4 | 0.7 mm | 35 | 8 | 3.2 | No. 2 | 50 | $26.80 | Add to Order |
| MSS-5543 | M4 | 0.7 mm | 40 | 8 | 3.2 | No. 2 | 50 | $30.91 | Add to Order |
| MSS-5542 | M4 | 0.7 mm | 45 | 8 | 3.2 | No. 2 | 25 | $17.18 | Add to Order |
| MSS-4984 | M4 | 0.7 mm | 50 | 8 | 3.2 | No. 2 | 25 | $17.41 | Add to Order |
| MSS-5541 | M4 | 0.7 mm | 60 | 8 | 3.2 | No. 2 | 25 | $19.47 | Add to Order |
| MSS-7070 | M4 | 0.7 mm | 70 | 8 | 3.2 | No. 2 | 50 | $30.91 | Add to Order |
| MSS-7071 | M4 | 0.7 mm | 80 | 8 | 3.2 | No. 2 | 25 | $33.79 | Add to Order |
| MSS-7072 | M4 | 0.7 mm | 100 | 8 | 3.2 | No. 2 | 25 | $34.92 | Add to Order |
| MSS-4998 | M5 | 0.8 mm | 6 | 10 | 3.9 | No. 2 | 50 | $15.46 | Add to Order |
| MSS-4999 | M5 | 0.8 mm | 8 | 10 | 3.9 | No. 2 | 50 | $16.38 | Add to Order |
| MSS-4500 | M5 | 0.8 mm | 10 | 10 | 3.9 | No. 2 | 50 | $17.05 | Add to Order |
| MSS-4501 | M5 | 0.8 mm | 12 | 10 | 3.9 | No. 2 | 50 | $19.28 | Add to Order |
| MSS-7073 | M5 | 0.8 mm | 14 | 10 | 3.9 | No. 2 | 50 | $22.91 | Add to Order |
| MSS-5540 | M5 | 0.8 mm | 16 | 10 | 3.9 | No. 2 | 50 | $21.92 | Add to Order |
| MSS-7074 | M5 | 0.8 mm | 18 | 10 | 3.9 | No. 2 | 50 | $24.34 | Add to Order |
| MSS-5590 | M5 | 0.8 mm | 20 | 10 | 3.9 | No. 2 | 50 | $22.83 | Add to Order |
| MSS-5524 | M5 | 0.8 mm | 25 | 10 | 3.9 | No. 2 | 50 | $25.83 | Add to Order |
| MSS-5587 | M5 | 0.8 mm | 30 | 10 | 3.9 | No. 2 | 25 | $17.30 | Add to Order |
| MSS-5621 | M5 | 0.8 mm | 35 | 10 | 3.9 | No. 2 | 25 | $18.31 | Add to Order |
| MSS-4529 | M5 | 0.8 mm | 40 | 10 | 3.9 | No. 2 | 25 | $18.84 | Add to Order |
| MSS-5622 | M5 | 0.8 mm | 45 | 10 | 3.9 | No. 2 | 25 | $24.04 | Add to Order |
| MSS-4556 | M5 | 0.8 mm | 50 | 10 | 3.9 | No. 2 | 25 | $21.29 | Add to Order |
| MSS-4557 | M5 | 0.8 mm | 60 | 10 | 3.9 | No. 2 | 10 | $11.55 | Add to Order |
| MSS-4558 | M5 | 0.8 mm | 70 | 10 | 3.9 | No. 2 | 10 | $11.59 | Add to Order |
| MSS-4559 | M5 | 0.8 mm | 80 | 10 | 3.9 | No. 2 | 10 | $19.26 | Add to Order |
| MSS-5623 | M6 | 1 mm | 8 | 12 | 4.7 | No. 3 | 25 | $15.39 | Add to Order |
| MSS-5624 | M6 | 1 mm | 10 | 12 | 4.7 | No. 3 | 25 | $14.83 | Add to Order |
| MSS-4562 | M6 | 1 mm | 12 | 12 | 4.7 | No. 3 | 25 | $15.29 | Add to Order |
| MSS-1343 | M6 | 1 mm | 16 | 12 | 4.7 | No. 3 | 25 | $15.77 | Add to Order |
| MSS-1344 | M6 | 1 mm | 20 | 12 | 4.7 | No. 3 | 25 | $16.76 | Add to Order |
| MSS-1346 | M6 | 1 mm | 30 | 12 | 4.7 | No. 3 | 25 | $21.76 | Add to Order |
| MSS-1347 | M6 | 1 mm | 35 | 12 | 4.7 | No. 3 | 25 | $25.77 | Add to Order |
| MSS-1347B | M6 | 1 mm | 40 | 12 | 4.7 | No. 3 | 25 | $24.07 | Add to Order |
| MSS-1348 | M6 | 1 mm | 45 | 12 | 4.7 | No. 3 | 25 | $26.99 | Add to Order |
| MSS-1349 | M6 | 1 mm | 50 | 12 | 4.7 | No. 3 | 25 | $28.92 | Add to Order |
| MSS-1363 | M6 | 1 mm | 60 | 12 | 4.7 | No. 3 | 10 | $14.76 | Add to Order |
| MSS-1351 | M6 | 1 mm | 70 | 12 | 4.7 | No. 3 | 10 | $15.90 | Add to Order |
| MSS-1340 | M6 | 1 mm | 80 | 12 | 4.7 | No. 3 | 10 | $16.55 | Add to Order |
| MSS-1353 | M6 | 1 mm | 90 | 12 | 4.7 | No. 3 | 5 | $10.82 | Add to Order |
| MSS-7075 | M8 | 1.25 mm | 10 | 16 | 6.1 | No. 4 | 25 | $31.21 | Add to Order |
| MSS-1354 | M8 | 1.25 mm | 12 | 16 | 6.1 | No. 4 | 10 | $11.55 | Add to Order |
| MSS-1355 | M8 | 1.25 mm | 16 | 16 | 6.1 | No. 4 | 10 | $14.03 | Add to Order |
| MSS-1356 | M8 | 1.25 mm | 20 | 16 | 6.1 | No. 4 | 10 | $14.89 | Add to Order |
| MSS-1357 | M8 | 1.25 mm | 25 | 16 | 6.1 | No. 4 | 10 | $16.57 | Add to Order |
| MSS-1358 | M8 | 1.25 mm | 30 | 16 | 6.1 | No. 4 | 10 | $18.04 | Add to Order |
| MSS-1359 | M8 | 1.25 mm | 35 | 16 | 6.1 | No. 4 | 10 | $21.44 | Add to Order |
| MSS-1360 | M8 | 1.25 mm | 40 | 16 | 6.1 | No. 4 | 10 | $21.71 | Add to Order |
| MSS-7076 | M8 | 1.25 mm | 45 | 16 | 6.1 | No. 4 | 10 | $32.76 | Add to Order |
| MSS-1361 | M8 | 1.25 mm | 50 | 16 | 6.1 | No. 4 | 10 | $24.32 | Add to Order |
| MSS-1329 | M8 | 1.25 mm | 60 | 16 | 6.1 | No. 4 | 5 | $17.75 | Add to Order |
| MSS-7077 | M10 | 1.5 mm | 25 | 20 | 7.5 | No. 4 | 5 | $27.49 | Add to Order |
| Rev. 08-23, 02-23, 11-22, 03-22 | |||||||||
