18-8 Stainless Steel Fillister Head Slotted Drive Machine Screws
Machine Screws - Fillister Head Slotted Drive, Class 2A, *fully threaded, combines head height and head diameter to maximize driving power, round top and flat bearing surface.
18-8 Stainless Steel - Excellent corrosion resistance, mildly magnetic, Rockwell hardness is B80, tensile strength 75,000 psi.
| 18-8 Stainless Steel Fillister Head Slotted
Machine Screws Passivated, ASME B18.6.3, Tensile Strength 70,000 PSI |
|||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-9317 | 0000-160 | 1/16" | 0.035" | 0.018" | 1 | $20.94 | Add to Order |
| MSS-9318 | 0000-160 | 3/32" | 0.035" | 0.018" | 1 | $20.94 | Add to Order |
| MSS-9319 | 0000-160 | 1/8" | 0.035" | 0.018" | 1 | $20.94 | Add to Order |
| MSS-9320 | 0000-160 | 5/32" | 0.035" | 0.018" | 1 | $20.94 | Add to Order |
| MSS-9321 | 000-120 | 3/32" | 0.056" | 0.031" | 1 | $4.77 | Add to Order |
| MSS-9322 | 000-120 | 1/8" | 0.056" | 0.031" | 1 | $4.77 | Add to Order |
| MSS-9323 | 000-120 | 3/16" | 0.056" | 0.031" | 1 | $5.02 | Add to Order |
| MSS-9324 | 000-120 | 1/4" | 0.056" | 0.031" | 1 | $5.25 | Add to Order |
| MSS-9325 | 00-90 | 1/8" | 0.082" | 0.047" | 1 | $5.25 | Add to Order |
| MSS-9326 | 00-90 | 3/16" | 0.082" | 0.047" | 1 | $5.25 | Add to Order |
| MSS-9327 | 00-90 | 1/4" | 0.082" | 0.047" | 1 | $5.52 | Add to Order |
| MSS-9328 | 00-96 | 1/8" | 0.082" | 0.047" | 1 | $5.25 | Add to Order |
| MSS-9329 | 00-96 | 3/16" | 0.082" | 0.047" | 1 | $5.25 | Add to Order |
| MSS-9330 | 00-96 | 1/4" | 0.082" | 0.047" | 1 | $5.52 | Add to Order |
| MSS-6143 | 0-80 | 1/8" | 0.096" | 0.055" | 100 | $23.12 | Add to Order |
| MSS-6144 | 0-80 | 3/16" | 0.096" | 0.055" | 100 | $23.96 | Add to Order |
| MSS-6145 | 0-80 | 1/4" | 0.096" | 0.055" | 100 | $25.81 | Add to Order |
| MSS-6146 | 0-80 | 5/16" | 0.096" | 0.055" | 100 | $26.94 | Add to Order |
| MSS-6147 | 0-80 | 3/8" | 0.096" | 0.055" | 100 | $27.62 | Add to Order |
| MSS-6160 | 0-80 | 1/2" | 0.096" | 0.055" | 50 | $16.15 | Add to Order |
| MSS-6149 | 0-80 | 5/8" | 0.096" | 0.055" | 50 | $16.88 | Add to Order |
| MSS-218 | 0-80 | 3/4" | 0.096" | 0.055" | 50 | $17.28 | Add to Order |
| MSS-219 | 0-80 | 1" | 0.096" | 0.055" | 50 | $20.50 | Add to Order |
| MSS-220 | 1-72 | 1/8" | 0.118" | 0.066" | 100 | $22.05 | Add to Order |
| MSS-221 | 1-72 | 3/16" | 0.118" | 0.066" | 100 | $23.69 | Add to Order |
| MSS-235 | 1-72 | 1/4" | 0.118" | 0.066" | 50 | $14.41 | Add to Order |
| MSS-223 | 1-72 | 3/8" | 0.118" | 0.066" | 50 | $15.10 | Add to Order |
| MSS-212 | 1-72 | 1/2" | 0.118" | 0.066" | 50 | $15.10 | Add to Order |
| MSS-225 | 1-72 | 5/8" | 0.118" | 0.066" | 50 | $17.87 | Add to Order |
| MSS-226 | 1-72 | 3/4" | 0.118" | 0.066" | 50 | $20.58 | Add to Order |
| MSS-227 | 1-72 | 1" | 0.118" | 0.066" | 25 | $12.03 | Add to Order |
| MSS-228 | 2-56 | 1/8" | 0.140" | 0.083" | 100 | $8.27 | Add to Order |
| MSS-229 | 2-56 | 3/16" | 0.140" | 0.083" | 100 | $6.09 | Add to Order |
| MSS-230 | 2-56 | 1/4" | 0.140" | 0.083" | 100 | $7.29 | Add to Order |
| MSS-231 | 2-56 | 5/16" | 0.140" | 0.083" | 100 | $6.93 | Add to Order |
| MSS-232 | 2-56 | 3/8" | 0.140" | 0.083" | 100 | $7.52 | Add to Order |
| MSS-233 | 2-56 | 7/16" | 0.140" | 0.083" | 100 | $5.48 | Add to Order |
| MSS-203B | 2-56 | 1/2" | 0.140" | 0.083" | 100 | $5.73 | Add to Order |
| MSS-224 | 2-56 | 5/8" | 0.140" | 0.083" | 100 | $9.18 | Add to Order |
| MSS-222 | 2-56 | 3/4" | 0.140" | 0.083" | 100 | $14.15 | Add to Order |
| MSS-190 | 2-56 | 7/8" | 0.140" | 0.083" | 100 | $14.34 | Add to Order |
| MSS-191 | 2-56 | 1" | 0.140" | 0.083" | 100 | $16.00 | Add to Order |
| MSS-9331 | 2-64 | 1/2" | 0.140" | 0.083" | 50 | $18.90 | Add to Order |
| MSS-192 | 3-48 | 1/8" | 0.161" | 0.095" | 100 | $23.98 | Add to Order |
| MSS-193 | 3-48 | 3/16" | 0.161" | 0.095" | 100 | $17.20 | Add to Order |
| MSS-194 | 3-48 | 1/4" | 0.161" | 0.095" | 100 | $13.73 | Add to Order |
| MSS-195 | 3-48 | 5/16" | 0.161" | 0.095" | 100 | $14.99 | Add to Order |
| MSS-196 | 3-48 | 3/8" | 0.161" | 0.095" | 100 | $15.81 | Add to Order |
| MSS-197 | 3-48 | 1/2" | 0.161" | 0.095" | 100 | $17.91 | Add to Order |
| MSS-198 | 3-48 | 5/8" | 0.161" | 0.095" | 100 | $22.41 | Add to Order |
| MSS-4549 | 3-48 | 3/4" | 0.161" | 0.095" | 50 | $13.08 | Add to Order |
| MSS-5644 | 3-48 | 1" | 0.161" | 0.095" | 50 | $18.63 | Add to Order |
| MSS-5635 | 4-40 | 1/8" | 0.183" | 0.107" | 100 | $18.38 | Add to Order |
| MSS-5642 | 4-40 | 3/16" | 0.183" | 0.107" | 100 | $8.88 | Add to Order |
| MSS-4982 | 4-40 | 1/4" | 0.183" | 0.107" | 100 | $10.69 | Add to Order |
| MSS-4911 | 4-40 | 5/16" | 0.183" | 0.107" | 100 | $7.29 | Add to Order |
| MSS-4505 | 4-40 | 3/8" | 0.183" | 0.107" | 100 | $6.72 | Add to Order |
| MSS-4915 | 4-40 | 7/16" | 0.183" | 0.107" | 100 | $12.73 | Add to Order |
| MSS-4916 | 4-40 | 1/2" | 0.183" | 0.107" | 100 | $14.97 | Add to Order |
| MSS-4917 | 4-40 | 5/8" | 0.183" | 0.107" | 100 | $9.18 | Add to Order |
| MSS-4918 | 4-40 | 3/4" | 0.183" | 0.107" | 100 | $11.13 | Add to Order |
| MSS-6138 | 4-40 | 1" | 0.183" | 0.107" | 100 | $12.31 | Add to Order |
| MSS-4919 | 4-40 | 1 1/4" | 0.183" | 0.107" | 100 | $17.81 | Add to Order |
| MSS-4920 | 4-40 | 1 1/2" | 0.183" | 0.107" | 100 | $21.04 | Add to Order |
| MSS-4921 | 4-48 | 1/4" | 0.183" | 0.107" | 50 | $14.68 | Add to Order |
| MSS-4922 | 4-48 | 3/8" | 0.183" | 0.107" | 50 | $16.15 | Add to Order |
| MSS-4936 | 4-48 | 1/2" | 0.183" | 0.107" | 50 | $18.67 | Add to Order |
| MSS-4924 | 4-48 | 3/4" | 0.183" | 0.107" | 50 | $22.34 | Add to Order |
| MSS-4913 | 4-48 | 1" | 0.183" | 0.107" | 25 | $15.90 | Add to Order |
| MSS-4926 | 5-40 | 3/16" | 0.205" | 0.120" | 100 | $18.75 | Add to Order |
| MSS-4927 | 5-40 | 1/4" | 0.205" | 0.120" | 100 | $14.01 | Add to Order |
| MSS-4928 | 5-40 | 5/16" | 0.205" | 0.120" | 100 | $14.91 | Add to Order |
| MSS-4929 | 5-40 | 3/8" | 0.205" | 0.120" | 100 | $16.59 | Add to Order |
| MSS-4930 | 5-40 | 1/2" | 0.205" | 0.120" | 100 | $18.08 | Add to Order |
| MSS-4931 | 5-40 | 3/4" | 0.205" | 0.120" | 100 | $12.73 | Add to Order |
| MSS-4932 | 5-40 | 1" | 0.205" | 0.120" | 100 | $14.81 | Add to Order |
| MSS-4933 | 6-32 | 3/16" | 0.226" | 0.132" | 100 | $12.37 | Add to Order |
| MSS-4934 | 6-32 | 1/4" | 0.226" | 0.132" | 100 | $12.24 | Add to Order |
| MSS-4902 | 6-32 | 5/16" | 0.226" | 0.132" | 100 | $8.78 | Add to Order |
| MSS-4925 | 6-32 | 3/8" | 0.226" | 0.132" | 100 | $9.37 | Add to Order |
| MSS-4923 | 6-32 | 1/2" | 0.226" | 0.132" | 100 | $14.66 | Add to Order |
| MSS-4891 | 6-32 | 5/8" | 0.226" | 0.132" | 100 | $9.53 | Add to Order |
| MSS-4892 | 6-32 | 3/4" | 0.226" | 0.132" | 100 | $9.45 | Add to Order |
| MSS-4893 | 6-32 | 7/8" | 0.226" | 0.132" | 100 | $13.76 | Add to Order |
| MSS-5650 | 6-32 | 1" | 0.226" | 0.132" | 100 | $14.81 | Add to Order |
| MSS-4895 | 6-32 | 1 1/4" | 0.226" | 0.132" | 100 | $10.79 | Add to Order |
| MSS-4896 | 6-32 | 1 1/2" | 0.226" | 0.132" | 100 | $19.61 | Add to Order |
| MSS-5640 | 6-32 | 2" | 0.226" | 0.132" | 50 | $20.75 | Add to Order |
| MSS-4898 | 8-32 | 3/16" | 0.270" | 0.156" | 100 | $24.42 | Add to Order |
| MSS-4899 | 8-32 | 1/4" | 0.270" | 0.156" | 100 | $9.79 | Add to Order |
| MSS-4912 | 8-32 | 5/16" | 0.270" | 0.156" | 100 | $10.52 | Add to Order |
| MSS-4901 | 8-32 | 3/8" | 0.270" | 0.156" | 100 | $17.39 | Add to Order |
| MSS-5639 | 8-32 | 1/2" | 0.270" | 0.156" | 100 | $12.08 | Add to Order |
| MSS-4903 | 8-32 | 5/8" | 0.270" | 0.156" | 100 | $23.14 | Add to Order |
| MSS-4904 | 8-32 | 3/4" | 0.270" | 0.156" | 100 | $13.92 | Add to Order |
| MSS-4905 | 8-32 | 7/8" | 0.270" | 0.156" | 100 | $14.57 | Add to Order |
| MSS-4906 | 8-32 | 1" | 0.270" | 0.156" | 100 | $15.69 | Add to Order |
| MSS-5638 | 8-32 | 1 1/4" | 0.270" | 0.156" | 100 | $21.36 | Add to Order |
| MSS-4908 | 8-32 | 1 1/2" | 0.270" | 0.156" | 50 | $19.66 | Add to Order |
| MSS-4909 | 8-32 | 1 3/4" | 0.270" | 0.156" | 50 | $19.95 | Add to Order |
| MSS-4910 | 8-32 | 2" | 0.270" | 0.156" | 50 | $24.78 | Add to Order |
| MSS-4947 | 8-32 | 2 1/2" | 0.270" | 0.156" | 25 | $16.28 | Add to Order |
| MSS-4900 | 10-24 | 5/16" | 0.313" | 0.180" | 100 | $27.62 | Add to Order |
| MSS-4935 | 10-24 | 3/8" | 0.313" | 0.180" | 100 | $21.53 | Add to Order |
| MSS-4961 | 10-24 | 1/2" | 0.313" | 0.180" | 100 | $22.39 | Add to Order |
| MSS-4962 | 10-24 | 5/8" | 0.313" | 0.180" | 100 | $18.94 | Add to Order |
| MSS-4963 | 10-24 | 3/4" | 0.313" | 0.180" | 50 | $20.62 | Add to Order |
| MSS-4964 | 10-24 | 1" | 0.313" | 0.180" | 50 | $24.13 | Add to Order |
| MSS-4965 | 10-24 | 1 1/4" | 0.313" | 0.180" | 50 | $30.03 | Add to Order |
| MSS-4966 | 10-24 | 1 1/2" | 0.313" | 0.180" | 50 | $32.84 | Add to Order |
| MSS-4967 | 10-24 | 2" | 0.313" | 0.180" | 25 | $20.62 | Add to Order |
| MSS-4968 | 10-24 | 3" | 0.313" | 0.180" | 25 | $26.44 | Add to Order |
| MSS-4969 | 10-32 | 1/4" | 0.313" | 0.180" | 100 | $27.95 | Add to Order |
| MSS-4983 | 10-32 | 5/16" | 0.313" | 0.180" | 100 | $27.62 | Add to Order |
| MSS-4971 | 10-32 | 3/8" | 0.313" | 0.180" | 100 | $29.42 | Add to Order |
| MSS-4960 | 10-32 | 7/16" | 0.313" | 0.180" | 100 | $30.07 | Add to Order |
| MSS-4973 | 10-32 | 1/2" | 0.313" | 0.180" | 100 | $27.38 | Add to Order |
| MSS-4974 | 10-32 | 5/8" | 0.313" | 0.180" | 100 | $35.24 | Add to Order |
| MSS-4975 | 10-32 | 3/4" | 0.313" | 0.180" | 50 | $20.62 | Add to Order |
| MSS-4976 | 10-32 | 7/8" | 0.313" | 0.180" | 50 | $21.76 | Add to Order |
| MSS-4977 | 10-32 | 1" | 0.313" | 0.180" | 50 | $24.13 | Add to Order |
| MSS-4978 | 10-32 | 1 1/4" | 0.313" | 0.180" | 50 | $30.03 | Add to Order |
| MSS-4979 | 10-32 | 1 1/2" | 0.313" | 0.180" | 100 | $65.69 | Add to Order |
| MSS-4980 | 10-32 | 1 3/4" | 0.313" | 0.180" | 50 | $34.57 | Add to Order |
| MSS-4981 | 10-32 | 2" | 0.313" | 0.180" | 25 | $21.13 | Add to Order |
| MSS-4949 | 10-32 | 2 1/4" | 0.313" | 0.180" | 25 | $21.80 | Add to Order |
| MSS-4972 | 10-32 | 2 1/2" | 0.313" | 0.180" | 25 | $22.51 | Add to Order |
| MSS-4970 | 10-32 | 3" | 0.313" | 0.180" | 25 | $26.44 | Add to Order |
| MSS-126 | 12-24 | 1/2" | 0.357" | 0.205" | 50 | $21.60 | Add to Order |
| MSS-127 | 12-24 | 5/8" | 0.357" | 0.205" | 50 | $22.30 | Add to Order |
| MSS-141 | 12-24 | 3/4" | 0.357" | 0.205" | 50 | $23.46 | Add to Order |
| MSS-9332 | 12-24 | 1" | 0.357" | 0.205" | 50 | $27.22 | Add to Order |
| MSS-9333B | 1/4"-20 | 3/8" | 0.414" | 0.237" | 50 | $23.88 | Add to Order |
| MSS-129 | 1/4"-20 | 1/2" | 0.414" | 0.237" | 50 | $21.97 | Add to Order |
| MSS-118 | 1/4"-20 | 5/8" | 0.414" | 0.237" | 50 | $24.09 | Add to Order |
| MSS-131 | 1/4"-20 | 3/4" | 0.414" | 0.237" | 25 | $13.92 | Add to Order |
| MSS-132 | 1/4"-20 | 1" | 0.414" | 0.237" | 25 | $17.01 | Add to Order |
| MSS-133 | 1/4"-20 | 1 1/4" | 0.414" | 0.237" | 50 | $20.98 | Add to Order |
| MSS-134 | 1/4"-20 | 1 1/2" | 0.414" | 0.237" | 50 | $22.13 | Add to Order |
| MSS-135 | 1/4"-20 | 2" | 0.414" | 0.237" | 25 | $23.12 | Add to Order |
| MSS-136 | 1/4"-28 | 1/2" | 0.414" | 0.237" | 25 | $13.52 | Add to Order |
| MSS-137 | 1/4"-28 | 5/8" | 0.414" | 0.237" | 25 | $14.89 | Add to Order |
| MSS-138 | 1/4"-28 | 3/4" | 0.414" | 0.237" | 25 | $18.54 | Add to Order |
| MSS-9334B | 1/4"-28 | 1" | 0.414" | 0.237" | 50 | $40.59 | Add to Order |
| MSS-139 | 5/16"-18 | 1/2" | 0.518" | 0.295" | 25 | $19.24 | Add to Order |
| MSS-107 | 5/16"-18 | 3/4" | 0.518" | 0.295" | 10 | $10.37 | Add to Order |
| MSS-3177 | 5/16"-18 | 1" | 0.518" | 0.295" | 10 | $11.97 | Add to Order |
| MSS-9335B | 5/16"-18 | 1 1/2" | 0.518" | 0.295" | 10 | $10.96 | Add to Order |
| MSS-3178 | 5/16"-18 | 1 3/4" | 0.518" | 0.295" | 10 | $17.98 | Add to Order |
| MSS-9336B | 5/16"-18 | 2" | 0.518" | 0.295" | 10 | $15.50 | Add to Order |
| MSS-9337B | 3/8"-16 | 1/2" | 0.622" | 0.355" | 10 | $20.56 | Add to Order |
| MSS-9338B | 3/8"-16 | 1" | 0.622" | 0.355" | 10 | $18.23 | Add to Order |
| MSS-9339B | 3/8"-16 | 2" | 0.622" | 0.355" | 5 | $15.92 | Add to Order |
| Rev. 10-23, 08-23, 02-23, 11-22 | |||||||
