Brass Binding Head Slotted Drive Machine Screws
Machine Screws - Binding Head Soltted Drive, Class 2A, fully threaded, large flat bearing surface good for electrical connections, thick, round head and tapered sides.
Brass - Nonmagnetic and good corrosion resistance, Rockwell hardness B55, tensile strength 53,000 psi.
| Brass Binding Head Slotted Machine Screws ASME B18.6.3, Tensile Strength 50,000 PSI, FT |
|||||||
| Part # | Thread Size | Length | Head Dia. | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| MSS-294 | 2-56 | 1/8" | 0.181" | 0.050" | 100 | $13.69 | Add to Order |
| MSS-283 | 2-56 | 3/16" | 0.181" | 0.050" | 100 | $14.62 | Add to Order |
| MSS-296 | 2-56 | 1/4" | 0.181" | 0.050" | 100 | $12.24 | Add to Order |
| MSS-299B | 4-40 | 3/16" | 0.235" | 0.068" | 100 | $14.74 | Add to Order |
| MSS-298 | 4-40 | 1/4" | 0.235" | 0.068" | 100 | $10.92 | Add to Order |
| MSS-299C | 4-40 | 5/16" | 0.235" | 0.068" | 100 | $17.47 | Add to Order |
| MSS-300 | 4-40 | 3/8" | 0.235" | 0.068" | 100 | $17.79 | Add to Order |
| MSS-301 | 4-40 | 1/2" | 0.235" | 0.068" | 100 | $15.65 | Add to Order |
| MSS-9428 | 4-40 | 3/4" | 0.257" | 0.063" | 100 | $17.07 | Add to Order |
| MSS-302 | 6-32 | 3/16" | 0.290" | 0.087" | 100 | $20.33 | Add to Order |
| MSS-303 | 6-32 | 1/4" | 0.290" | 0.087" | 100 | $21.32 | Add to Order |
| MSS-340 | 6-32 | 5/16" | 0.290" | 0.087" | 100 | $25.12 | Add to Order |
| MSS-293 | 6-32 | 3/8" | 0.290" | 0.087" | 100 | $15.54 | Add to Order |
| MSS-570 | 6-32 | 1/2" | 0.290" | 0.087" | 100 | $28.08 | Add to Order |
| MSS-354 | 6-32 | 3/4" | 0.290" | 0.087" | 100 | $35.07 | Add to Order |
| MSS-9529 | 6-32 | 1" | 0.321" | 0.080" | 100 | $27.24 | Add to Order |
| MSS-355 | 8-32 | 1/4" | 0.344" | 0.105" | 100 | $19.32 | Add to Order |
| MSS-356 | 8-32 | 5/16" | 0.344" | 0.105" | 100 | $29.78 | Add to Order |
| MSS-357 | 8-32 | 3/8" | 0.344" | 0.105" | 100 | $32.38 | Add to Order |
| MSS-358 | 8-32 | 1/2" | 0.344" | 0.105" | 100 | $36.88 | Add to Order |
| MSS-359 | 8-32 | 3/4" | 0.344" | 0.105" | 50 | $20.41 | Add to Order |
| MSS-9530 | 8-32 | 1" | 0.344" | 0.105" | 50 | $23.92 | Add to Order |
| MSS-9531 | 10-24 | 3/8" | 0.399" | 0.123" | 50 | $20.08 | Add to Order |
| MSS-9532 | 10-24 | 1/2" | 0.399" | 0.123" | 50 | $25.47 | Add to Order |
| MSS-376 | 10-24 | 3/4" | 0.399" | 0.123" | 50 | $28.48 | Add to Order |
| MSS-364 | 10-24 | 1" | 0.399" | 0.123" | 25 | $18.06 | Add to Order |
| MSS-353 | 10-32 | 1/4" | 0.399" | 0.123" | 100 | $38.26 | Add to Order |
| MSS-366 | 10-32 | 5/16" | 0.399" | 0.123" | 50 | $19.59 | Add to Order |
| MSS-367 | 10-32 | 3/8" | 0.399" | 0.123" | 50 | $21.90 | Add to Order |
| MSS-368 | 10-32 | 1/2" | 0.399" | 0.123" | 50 | $22.16 | Add to Order |
| MSS-369 | 10-32 | 3/4" | 0.399" | 0.123" | 50 | $28.01 | Add to Order |
| MSS-9533 | 10-32 | 1" | 0.399" | 0.123" | 25 | $21.13 | Add to Order |
| MSS-9534 | 1/4"-20 | 3/8" | 0.573" | 0.153" | 25 | $17.01 | Add to Order |
| MSS-9535 | 1/4"-20 | 1/2" | 0.573" | 0.153" | 25 | $18.54 | Add to Order |
| MSS-9536 | 1/4"-20 | 3/4" | 0.573" | 0.153" | 25 | $22.76 | Add to Order |
| MSS-9537 | 1/4"-20 | 1" | 0.573" | 0.153" | 25 | $26.38 | Add to Order |
| MSS-9538 | 1/4"-20 | 1 1/2" | 0.573" | 0.153" | 10 | $14.81 | Add to Order |
| Rev. 03-24, 08-23, 02-23, 11-22 | |||||||
