18-8 Stainless Steel Lock Nuts
Insert has a maximum temperature of 220°F
18-8 Stainless Steel - Black Oxide Coated
18-8 Stainless Steel - Metric Sizes
18-8 Stainless Steel - Black Oxide Coated
18-8 Stainless Steel - Metric Sizes
| 18-8 Stainless Steel Lock Nut - Hex Nuts | ||||||
| Part # | Thread Size | Width | Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|
| HN-1255B | 2-56 | 1/4" | 9/64" | 50 | $6.13 | Add to Order |
| HN-1256 | 3-48 | 1/4" | 9/64" | 50 | $10.27 | Add to Order |
| HN-1257 | 4-40 | 1/4" | 9/64" | 100 | $11.05 | Add to Order |
| HN-1454 | 4-40 | 1/4" | 7/64" | 50 | $9.70 | Add to Order |
| HN-1258 | 5-40 | 1/4" | 9/64" | 100 | $15.62 | Add to Order |
| HN-1259 | 6-32 | 5/16" | 11/64" | 100 | $8.42 | Add to Order |
| HN-1455 | 6-32 | 5/16" | 1/8" | 100 | $25.03 | Add to Order |
| HN-1260 | 6-40 | 5/16" | 11/64" | 100 | $18.69 | Add to Order |
| HN-1261 | 8-32 | 11/32" | 15/64" | 100 | $14.49 | Add to Order |
| HN-1456 | 8-32 | 11/32" | 11/64" | 100 | $16.21 | Add to Order |
| HN-1262 | 8-36 | 11/32" | 15/64" | 100 | $22.81 | Add to Order |
| HN-1263 | 10-24 | 3/8" | 15/64" | 100 | $14.45 | Add to Order |
| HN-1457 | 10-24 | 3/8" | 11/64" | 200 | $47.88 | Add to Order |
| HN-1264 | 10-32 | 3/8" | 15/64" | 100 | $14.45 | Add to Order |
| HN-1458 | 10-32 | 3/8" | 11/64" | 50 | $9.89 | Add to Order |
| HN-1265 | 12-24 | 7/16" | 5/16" | 50 | $20.69 | Add to Order |
| HN-1266 | 12-28 | 7/16" | 5/16" | 50 | $31.46 | Add to Order |
| HN-1267 | 1/4"-20 | 7/16" | 5/16" | 50 | $13.46 | Add to Order |
| HN-1459 | 1/4"-20 | 7/16" | 13/64" | 50 | $9.07 | Add to Order |
| HN-1500 | 1/4"-20 | 1/2" | 3/8" | 10 | $16.63 | Add to Order |
| HN-1528 | 1/4"-20 | 1/2" | 9/32" | 25 | $34.19 | Add to Order |
| HN-1268 | 1/4"-28 | 7/16" | 5/16" | 100 | $31.88 | Add to Order |
| HN-1460 | 1/4"-28 | 7/16" | 13/64" | 50 | $8.44 | Add to Order |
| HN-1269 | 5/16"-18 | 1/2" | 11/32" | 50 | $16.80 | Add to Order |
| HN-1461 | 5/16"-18 | 1/2" | 1/4" | 50 | $11.95 | Add to Order |
| HN-1501 | 5/16"-18 | 9/16" | 7/16" | 5 | $10.50 | Add to Order |
| HN-1529 | 5/16"-18 | 9/16" | 5/16" | 20 | $34.73 | Add to Order |
| HN-1270 | 5/16"-24 | 1/2" | 11/32" | 50 | $12.33 | Add to Order |
| HN-1462 | 5/16"-24 | 1/2" | 1/4" | 50 | $11.95 | Add to Order |
| HN-1271 | 3/8"-16 | 9/16" | 29/64" | 50 | $17.18 | Add to Order |
| HN-1463 | 3/8"-16 | 9/16" | 17/64" | 25 | $18.59 | Add to Order |
| HN-1502 | 3/8"-16 | 11/16" | 35/64" | 5 | $18.98 | Add to Order |
| HN-1530 | 3/8"-16 | 11/16" | 13/32" | 10 | $31.08 | Add to Order |
| HN-1272 | 3/8"-24 | 9/16" | 29/64" | 50 | $10.42 | Add to Order |
| HN-1464 | 3/8"-24 | 9/16" | 17/64" | 25 | $13.99 | Add to Order |
| HN-1273 | 7/16"-14 | 5/8" | 29/64" | 25 | $11.15 | Add to Order |
| HN-1465 | 7/16"-14 | 5/8" | 5/16" | 10 | $16.99 | Add to Order |
| HN-1531 | 7/16"-14 | 3/4" | 7/16" | 25 | $20.10 | Add to Order |
| HN-1274 | 7/16"-20 | 5/8" | 29/64" | 25 | $15.14 | Add to Order |
| HN-1466 | 7/16"-20 | 5/8" | 5/16" | 5 | $10.19 | Add to Order |
| HN-1275 | 1/2"-13 | 3/4" | 19/32" | 10 | $7.27 | Add to Order |
| HN-1467 | 1/2"-13 | 3/4" | 5/16" | 10 | $11.63 | Add to Order |
| HN-1504 | 1/2"-13 | 7/8" | 45/64" | 1 | $6.89 | Add to Order |
| HN-1532 | 1/2"-13 | 7/8" | 17/32" | 5 | $4.98 | Add to Order |
| HN-1276 | 1/2"-20 | 3/4" | 19/32" | 10 | $10.10 | Add to Order |
| HN-1468 | 1/2"-20 | 3/4" | 5/16" | 5 | $10.77 | Add to Order |
| HN-1277 | 9/16"-12 | 7/8" | 41/64" | 1 | $4.10 | Add to Order |
| HN-1278 | 9/16"-18 | 7/8" | 41/64" | 5 | $16.99 | Add to Order |
| HN-1469 | 9/16"-18 | 7/8" | 23/64" | 1 | $46.98 | Add to Order |
| HN-1279 | 5/8"-11 | 15/16" | 3/4" | 10 | $19.53 | Add to Order |
| HN-1470 | 5/8"-11 | 15/16" | 25/64" | 1 | $6.78 | Add to Order |
| HN-1533 | 5/8"-11 | 1 1/16" | 39/64" | 1 | $17.54 | Add to Order |
| HN-1505 | 5/8"-11 | 1 1/16" | 55/64" | 1 | $14.45 | Add to Order |
| HN-1280 | 5/8"-18 | 15/16" | 3/4" | 10 | $22.05 | Add to Order |
| HN-1471 | 5/8"-18 | 15/16" | 25/64" | 1 | $3.57 | Add to Order |
| HN-1281 | 3/4"-10 | 1 1/16" | 7/8" | 5 | $12.47 | Add to Order |
| HN-1472 | 3/4"-10 | 1 1/16" | 13/32" | 1 | $6.59 | Add to Order |
| HN-1506 | 3/4"-10 | 1 1/4" | 1.0" | 1 | $44.10 | Add to Order |
| HN-1534 | 3/4"-10 | 1 1/4" | 45/64 | 1 | $26.25 | Add to Order |
| HN-1282 | 3/4"-16 | 1 1/16" | 7/8" | 5 | $14.55 | Add to Order |
| HN-1473 | 3/4"-16 | 1 1/16" | 13/32" | 1 | $19.53 | Add to Order |
| HN-1283 | 7/8"-9 | 1 1/4" | 63/64" | 1 | $10.04 | Add to Order |
| HN-1474 | 7/8"-9 | 1 1/4" | 15/32" | 1 | $17.07 | Add to Order |
| HN-1507 | 7/8"-9 | 1 7/16" | 1 9/64" | 1 | $93.74 | Add to Order |
| HN-1284 | 7/8"-14 | 1 1/4" | 63/64" | 1 | $18.86 | Add to Order |
| HN-1475 | 7/8"-14 | 1 1/4" | 15/32" | 1 | $27.07 | Add to Order |
| HN-1285 | 1"-8 | 1 7/16" | 1 3/64" | 1 | $13.92 | Add to Order |
| HN-1476 | 1"-8 | 1 7/16" | 35/64" | 1 | $20.94 | Add to Order |
| HN-1508 | 1"-8 | 1 5/8" | 1 5/16" | 1 | $95.38 | Add to Order |
| HN-1535 | 1"-8 | 1 5/8" | 59/64" | 1 | $44.63 | Add to Order |
| HN-1286 | 1"-12 | 1 7/16" | 1 3/64" | 1 | $24.74 | Add to Order |
| HN-1287 | 1"-14 | 1 7/16" | 1 3/64" | 1 | $17.30 | Add to Order |
| HN-1477 | 1"-14 | 1 7/16" | 35/64" | 1 | $30.81 | Add to Order |
| HN-1288 | 1 1/8"-7 | 1 5/8" | 1 11/64" | 1 | $26.67 | Add to Order |
| HN-1478 | 1 1/8"-7 | 1 5/8" | 41/64" | 1 | $27.89 | Add to Order |
| HN-1289 | 1 1/4"-7 | 1 13/16" | 1 25/64" | 1 | $35.47 | Add to Order |
| HN-1479 | 1 1/4"-7 | 1 13/16" | 3/4" | 1 | $37.51 | Add to Order |
| HN-1480 | 1 1/4"-12 | 1 13/16" | 3/4" | 1 | $87.95 | Add to Order |
| HN-1290 | 1 1/2"-6 | 2 13/64" | 1 39/64" | 1 | $41.29 | Add to Order |
| HN-1481 | 1 1/2"-6 | 2 13/64" | 51/64" | 1 | $45.34 | Add to Order |
| Rev. 10-23, 04-23, 01-23, 12-22 | ||||||
| 18-8 Stainless Steel Metric Lock Nuts, DIN 985 A2 Stainless Steel |
||||||||
| Part # | Thread Size | Pitch (mm) | Width (mm) | Height (mm) | Pkg. Qty | Pkg. Price | Order Online | |
|---|---|---|---|---|---|---|---|---|
| HN-1299 | M2 | 0.4 | 4 | 2.8 | 10 | $19.53 | Add to Order | |
| HN-1300 | M2.5 | 0.45 | 5 | 3.8 | 100 | $27.34 | Add to Order | |
| HN-1301 | M3 | 0.5 | 5.5 | 4 | 100 | $14.57 | Add to Order | |
| HN-1302 | M4 | 0.7 | 7 | 5 | 100 | $16.11 | Add to Order | |
| HN-1303 | M5 | 0.8 | 8 | 5 | 100 | $18.42 | Add to Order | |
| HN-1304 | M6 | 1 | 10 | 6 | 100 | $23.46 | Add to Order | |
| HN-1305 | M8 | 1.25 | 13 | 8 | 50 | $21.27 | Add to Order | |
| HN-1306 | M10 | 1.5 | 17 | 10 | 20 | $26.04 | Add to Order | |
| HN-1307 | M12 | 1.75 | 19 | 12 | 25 | $42.06 | Add to Order | |
| HN-1308 | M14 | 2 | 22 | 14 | 10 | $22.05 | Add to Order | |
| HN-1309 | M16 | 2 | 24 | 16 | 5 | $15.75 | Add to Order | |
| HN-1310 | M18 | 2.5 | 27 | 18.5 | 1 | $16.11 | Add to Order | |
| HN-1311 | M20 | 2.5 | 30 | 20 | 5 | $33.60 | Add to Order | |
| HN-1312 | M24 | 3 | 36 | 24 | 2 | $45.61 | Add to Order | |
| HN-1313 | M27 | 3 | 41 | 27 | 1 | $42.02 | Add to Order | |
| HN-1314 | M30 | 3.5 | 46 | 30 | 1 | $38.85 | Add to Order | |
| Rev. 04-23, 01-23, 12-22, 03-22 | ||||||||
| 18-8 Stainless Steel Lock Nuts - Black Oxide Coated | ||||||
| Part # | Thread Size | Width | Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|
| HN-1291 | 4-40 | 1/4" | 9/64" | 100 | $23.10 | Add to Order |
| HN-1292 | 6-32 | 5/16" | 11/64" | 100 | $22.49 | Add to Order |
| HN-1293 | 8-32 | 11/32" | 15/64" | 100 | $27.45 | Add to Order |
| HN-1294 | 10-24 | 3/8" | 15/64" | 100 | $30.16 | Add to Order |
| HN-1295 | 1/4"-20 | 7/16" | 5/16" | 50 | $27.15 | Add to Order |
| HN-1296 | 5/16"-18 | 1/2" | 11/32" | 50 | $32.63 | Add to Order |
| HN-1297 | 3/8"-16 | 9/16" | 29/64" | 25 | $35.34 | Add to Order |
| HN-1298 | 1/2"-13 | 3/4" | 19/32" | 10 | $27.15 | Add to Order |
| Rev. 12-22, 02-22, 07-21, 06-21 | ||||||
| 304 Stainless Steel Flanged Serrated Lock Nuts | ||||||||
| Part # | Thread Size | Width | Height | Flange Dia. | Flange Thick. | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| HN-2647 | 6-32 | 5/16" | 11/64" | 27/64" | 0.07" | 50 | $12.47 | Add to Order |
| HN-2648 | 8-32 | 11/32" | 13/64" | 15/32" | 0.07" | 50 | $9.14 | Add to Order |
| HN-2649 | 10-24 | 3/8" | 7/32" | 1/2" | 0.09" | 50 | $14.45 | Add to Order |
| HN-2650 | 10-32 | 3/8" | 7/32" | 1/2" | 0.09" | 50 | $14.45 | Add to Order |
| HN-2651 | 1/4"-20 | 7/16" | 15/64" | 19/32" | 0.1" | 50 | $16.17 | Add to Order |
| HN-2652 | 1/4"-28 | 7/16" | 15/64" | 19/32" | 0.1" | 25 | $10.46 | Add to Order |
| HN-2653 | 5/16"-18 | 1/2" | 9/32" | 43/64" | 0.11" | 25 | $12.68 | Add to Order |
| HN-2654 | 5/16"-24 | 1/2" | 9/32" | 43/64" | 0.11" | 10 | $8.11 | Add to Order |
| HN-2655 | 3/8"-16 | 9/16" | 11/32" | 3/4" | 0.12" | 25 | $16.19 | Add to Order |
| HN-2656 | 3/8"-24 | 9/16" | 11/32" | 3/4" | 0.12" | 10 | $10.54 | Add to Order |
| HN-2657 | 1/2"-13 | 3/4" | 29/64" | 1 1/32" | 0.15" | 10 | $17.39 | Add to Order |
| HN-2658 | 1/2"-20 | 3/4" | 29/64" | 1 1/32" | 0.05" | 10 | $23.00 | Add to Order |
| Rev. 04-23, 01-23, 12-22 | ||||||||
| 18-8 A2 Stainless Steel Metric Flanged Locknuts DIN 6923 | |||||||||
| Part # | Thread Size | Pitch (mm) | Width mm | Height mm | Flange Dia. | Flange Thick. | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| HN-2666 | M4 | 0.7 | 7 | 6.1 | 10.2 | 1.2 | 10 | $21.23 | Add to Order |
| HN-2667 | M5 | 0.8 | 8 | 7.1 | 11.8 | 1 | 10 | $25.85 | Add to Order |
| HN-2668 | M6 | 1 | 10 | 9.1 | 14.2 | 1.1 | 10 | $30.49 | Add to Order |
| HN-2672 | M6 | 1 | 10 | 6 | 14.2 | 1.19 | 50 | $18.38 | Add to Order |
| HN-2673 | M8 | 1.25 | 13 | 8 | 17.9 | 1.31 | 25 | $20.54 | Add to Order |
| HN-2669 | M8 | 1.25 | 13 | 11.1 | 17.9 | 1.2 | 5 | $21.23 | Add to Order |
| HN-2670 | M10 | 1.5 | 15 | 13.5 | 21.8 | 1.5 | 5 | $30.49 | Add to Order |
| HN-2674 | M10 | 1.5 | 15 | 10 | 21.8 | 1.81 | 10 | $13.48 | Add to Order |
| HN-2675 | M12 | 1.75 | 18 | 12 | 26 | 2.2 | 10 | $24.07 | Add to Order |
| HN-2671 | M12 | 1.75 | 18 | 16.1 | 26 | 1.8 | 1 | $9.24 | Add to Order |
| Rev. 12-22 | |||||||||
| 18-8 A2 Stainless Steel Serrated Flanged Lock Nuts | |||||||||
| Part # | Thread Size | Pitch (mm) | Width mm | Height mm | Flange Dia. | Flange Thick. | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|---|
| HN-2659 | M6 | 1 | 10 | 6 | 14.2 | 1.18 | 50 | $13.90 | Add to Order |
| HN-2660 | M8 | 1.25 | 13 | 8 | 17.9 | 1.3 | 25 | $13.36 | Add to Order |
| HN-2661 | M10 | 1.5 | 15 | 10 | 21.8 | 1.8 | 25 | $20.87 | Add to Order |
| HN-2662 | M12 | 1.75 | 18 | 12 | 26 | 2.19 | 10 | $16.63 | Add to Order |
| Rev. 04-23, 12-22 | |||||||||
