| | 101 Copper
Sheets > 110 Copper Sheets
101 Alloy Copper Electrical
Grade Sheets and Plates
Pure Copper 99.99% Oxygen
Free
Weldable - Brazable
Type 1 - F77-F89 Rockwell, 30K-44K
PSI Yield Strength, 1/2 (H02) Hard, ASTM B152
Type 2 - F30-F75 Rockwell, 10K PSI,
Yield Strength, 1/2 (H02) Hard, ASTM F68
Type 3 - Rockwell F77-F89. 36K PSI
Yield Strength: 1/2 Hard (H02). Meets ASTM F68.
Order Copper
Sheets/Plates Online - Click Here
Technical Data
C10100 Copper Sheets
| Thickness
Inch |
Width
Inch |
Length
Inch |
Type |
Length
Tol Inch |
Stock# |
Price
Each |
| .020" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3323 |
$33.20 |
| .020" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3310 |
$85.38 |
| .032" |
12.00" |
12.00" |
1 |
+/-.125" |
MS-3218 |
$64.44 |
| .032" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3313 |
$49.12 |
| .032" |
12.00" |
24.00" |
1 |
+/-.125" |
MS-3221 |
$113.18 |
| .032" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3376 |
$127.40 |
| .032" |
12.00" |
48.00" |
1 |
+/-.125" |
MS-3217 |
$206.22 |
| .032" |
24.00" |
48.00" |
1 |
+/-.125" |
MS-726 |
$378.78 |
| .032" |
6.00" |
6.00" |
1 |
+/-.125" |
MS-3196 |
$29.00 |
| .040" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3312 |
$56.12 |
| .040" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3375 |
$147.30 |
| .050" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3311 |
$64.36 |
| .050" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3374 |
$174.72 |
| .062" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3273 |
$75.86 |
| .062" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3206 |
$206.82 |
| .064" |
12.00" |
12.00" |
1 |
+/-.125" |
MS-3201 |
$116.00 |
| .064" |
12.00" |
24.00" |
1 |
+/-.125" |
MS-3220 |
$206.22 |
| .064" |
12.00" |
48.00" |
1 |
+/-.125" |
MS-3225 |
$386.66 |
| .064" |
24.00" |
48.00" |
1 |
+/-.125" |
MS-779 |
$727.84 |
| .064" |
6.00" |
6.00" |
1 |
+/-.125" |
MS-3195 |
$55.24 |
| .093" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3162 |
$108.34 |
| .093" |
12.00" |
12.00" |
1 |
+/-.125" |
MS-3223 |
$153.18 |
| .093" |
12.00" |
24.00" |
1 |
+/-.125" |
MS-3219 |
$299.56 |
| .093" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3205 |
$296.74 |
| .093" |
12.00" |
48.00" |
1 |
+/-.125" |
MS-3215 |
$539.20 |
| .093" |
24.00" |
48.00" |
1 |
+/-.125" |
MS-778 |
$980.36 |
| .093" |
6.00" |
6.00" |
1 |
+/-.125" |
MS-3194 |
$76.82 |
| .125" |
12.00" |
12.00" |
1 |
+/-.125" |
MS-3222 |
$186.22 |
| .125" |
12.00" |
12.00" |
2 |
+/-.062" |
MS-3293 |
$127.42 |
| .125" |
12.00" |
24.00" |
1 |
+/-.125" |
MS-3209 |
$335.20 |
| .125" |
12.00" |
36.00" |
2 |
+/-.062" |
MS-3204 |
$352.80 |
| .125" |
12.00" |
48.00" |
1 |
+/-.125" |
MS-783 |
$609.46 |
| .125" |
24.00" |
48.00" |
1 |
+/-.125" |
MS-777 |
$1,155.86 |
| .125" |
6.00" |
6.00" |
1 |
+/-.125" |
MS-3216 |
$95.00 |
| .250" |
12.00" |
12.00" |
1 |
+/-.375" |
MS-3587 |
$334.80 |
| .250" |
12.00" |
24.00" |
1 |
+/-.375" |
MS-3592 |
$608.72 |
| .250" |
12.00" |
48.00" |
1 |
+/-.375" |
MS-3589 |
$1,154.48 |
| .250" |
24.00" |
48.00" |
1 |
+/-.375" |
MS-3612 |
$2,125.72 |
| .250" |
6.00" |
6.00" |
1 |
+/-.375" |
MS-3598 |
$167.60 |
| .375" |
12.00" |
12.00" |
1 |
+/-.375" |
MS-3594 |
$483.08 |
| .375" |
12.00" |
24.00" |
1 |
+/-.375" |
MS-3591 |
$866.20 |
| .375" |
12.00" |
48.00" |
1 |
+/-.375" |
MS-3588 |
$1,620.64 |
| .375" |
24.00" |
48.00" |
1 |
+/-.375" |
MS-3595 |
$2,912.46 |
| .375" |
6.00" |
6.00" |
1 |
+/-.375" |
MS-3597 |
$228.36 |
| .500" |
12.00" |
12.00" |
1 |
+/-.375" |
MS-3602 |
$609.12 |
| .500" |
12.00" |
24.00" |
1 |
+/-.375" |
MS-3590 |
$1,116.00 |
| .500" |
12.00" |
48.00" |
1 |
+/-.375" |
MS-3610 |
$2,060.30 |
| .500" |
24.00" |
48.00" |
1 |
+/-.375" |
MS-3617 |
$3,881.74 |
| .500" |
6.00" |
6.00" |
1 |
+/-.375" |
MS-3596 |
$279.00 |
| .625" |
6.00" |
6.00" |
3 |
+/-.25" |
MS-3603 |
$260.14 |
| .625" |
9.00" |
9.00" |
3 |
+/-.25" |
MS-3619 |
$546.26 |
| .750" |
6.00" |
6.00" |
3 |
+/-.25" |
MS-3611 |
$285.00 |
| .750" |
9.00" |
9.00" |
3 |
+/-.25" |
MS-3609 |
$589.96 |
| .875" |
6.00" |
6.00" |
3 |
+/-.25" |
MS-3608 |
$293.92 |
| .875" |
9.00" |
9.00" |
3 |
+/-.25" |
MS-3606 |
$625.28 |
| 1.00' |
6.00" |
6.00" |
3 |
+/-.25" |
MS-3607 |
$306.66 |
| 1.00' |
9.00" |
9.00" |
3 |
+/-.25" |
MS-3605 |
$655.50 |
Note: with the
volatile steel, metal, copper, etc market rapidly changing, pricing is not
guaranteed and will be reviewed upon order.
Thickness Tolerances:
| Thickness |
Thickness Tolerance |
| .020"-.032" |
+/-.0035" |
| .040"
-.064" |
+/-.005" |
| .093"-.125" |
+/-.007" |
| .250" |
+/-.009" |
| .375" |
+/-.012" |
| .500" |
+/-.015" |
| .625" -
.750" |
+/-.019" |
|
.875" - 1.00" |
+/-.024" |
| |
|
