Brass
Balls
Brass
balls provide excellent resistance to corrosion by water, and they
are substantially lower in cost than other corrosion-resisting balls.
Brass balls are frequently used in many types of valve applications
requiring small-size balls.
Brass
balls also have the ability to resist the corrosive effects of fuel oil,
gasoline, butane, dry carbon dioxide, benzene, lime-sulphur mixture and
similar chemical agents.
|
|
|
|
|
|
|
Balls
per Pound
|
|
Size
|
Balls
per Pound
|
|
Inches
|
Millimeters
|
|
1/8
|
3.175
|
3,200
|
|
5/32
|
3.968
|
1,640
|
|
3/16
|
4.762
|
947
|
|
7/32
|
5.556
|
596
|
|
1/4
|
6.350
|
400
|
|
9/32
|
7.143
|
281
|
|
5/16
|
7.937
|
205
|
|
11/32
|
8.731
|
154
|
|
3/8
|
9.525
|
118
|
|
7/16
|
11.112
|
74.5
|
|
1/2
|
12.700
|
50.0
|
|
9/16
|
14.287
|
35.1
|
|
5/8
|
15.875
|
25.6
|
|
11/16
|
17.462
|
19.2
|
|
3/4
|
19.050
|
14.8
|
|
|
|
|
|
|
Material
Analysis:
Material
is SAE specification CA260 alloy.
|
|
|
|
|
|
|
Material
|
CDA
|
Federal
|
Military
|
ASTM
|
UNS
|
AMS
|
Military
and
Gov't Stds.
|
|
Brass
|
260
|
QQ-W-321c
Comp.7
|
MILW-6712A
Type II
|
B134-52
Alloy 7
|
C-26000
|
4712A
4713A
|
MS
19062
CCAX2
|
|
|
|
|
|
|
|
Chemical
Analysis:
Copper......................................................................68.50%
to 71.50%
Lead..........................................................................0.07%
maximum
Iron............................................................................0.05%
maximum
Zinc...........................................................................Balance
|
|
|
|
|
Mechanical
Properties:
Hardness
as measured on parallel flat surfaces is Rockwell “B” 75 to 87.
Tensile
Strength............................................................80,000psi
Yield
Strength................................................................57,000psi
Elongation in two
inches..............................................20%
Reduction in
area.........................................................85%
Modulus of
elasticity.....................................................15,000,000psi
Density...........................................................................0.306
lbs/cu. in.
©
copyright 2005 Hoover Precision Products, Inc., All Rights Reserved
|
-
|
Brass Balls
Click
Here for Ball Terms and Definitions (Grades Available and Tolerances)
Click
here to Order Online |
| Balls per
Pkg |
Stock # |
Grade # |
Diameter |
Price/Pkg |
| 1000 |
KB-828 |
5 |
0.062 |
$59.24 |
| 5000 |
KB-830 |
300 |
0.062 |
$242.40 |
| 5000 |
KB-840 |
200 |
0.062 |
$266.60 |
| 100 |
KB-1785 |
200 |
0.062 |
$15.44 |
| 100 |
KB-1786 |
200 |
0.093 |
$14.76 |
| 100 |
KB-1787 |
200 |
0.125 |
$8.44 |
| 100 |
KB-1788 |
200 |
0.156 |
$10.04 |
| 10000 |
KB-820 |
200 |
0.187 |
$344.40 |
| 100 |
KB-1799 |
200 |
0.187 |
$10.56 |
| 100 |
KB-1790 |
200 |
0.218 |
$18.68 |
| 4350 |
KB-832 |
200 |
0.250 |
$318.33 |
| 100 |
KB-1782 |
200 |
0.250 |
$22.68 |
| 3000 |
KB-833 |
200 |
0.281 |
$274.80 |
| 2200 |
KB-834 |
200 |
0.312 |
$288.11 |
| 50 |
KB-1792 |
200 |
0.312 |
$19.78 |
| 1650 |
KB-835 |
200 |
0.343 |
$254.69 |
| 50 |
KB-1793 |
200 |
0.343 |
$29.54 |
| 1300 |
KB-836 |
200 |
0.375 |
$268.71 |
| 50 |
KB-1794 |
200 |
0.375 |
$29.58 |
| 25 |
KB-1795 |
200 |
0.437 |
$29.66 |
| 550 |
KB-837 |
200 |
0.500 |
$237.95 |
| 25 |
KB-1796 |
200 |
0.500 |
$29.88 |
| 20 |
KB-1797 |
200 |
0.562 |
$29.22 |
| 275 |
KB-838 |
200 |
0.625 |
$262.66 |
| 15 |
KB-1826 |
200 |
0.625 |
$29.84 |
| 160 |
KB-810 |
200 |
0.750 |
$271.24 |
| 5 |
KB-1825 |
200 |
0.750 |
$21.64 |
| |
|
