260 Brass Sheets, Foils and Plates

Brass Shim

Technical Data

260 Brass Strips/Plates

ASTM B36

Part # Thickness Thickness Tolerance Width Length Price Order Online
MS-181 .001" +-.0001" 6.00" 25" $43.40 Add to Order
MS-213 .001" +-.0001" 6.00" 100" $28.68 Add to Order
MS-237 .0015" +-.0015" 6.00" 60" $24.12 Add to Order
MS-220 .0015" +-.0015" 6.00" 100" $33.48 Add to Order
MS-608 .002" -0.0003 .500" 1200" $419.80 Add to Order
MS-2116 .002" +-.0002" 6.00" 60" $24.68 Add to Order
MS-2220 .002" +-.0002" 6.00" 100" $32.42 Add to Order
MS-2219 .002" +-.0003" 12" 120" $62.60 Add to Order
MS-2210 .003" +-.0003" 6.00" 60" $25.06 Add to Order
MS-2217 .003" +-.0003" 6.00" 100" $67.10 Add to Order
MS-2225 .003" +-.0003" 12" 120" $80.18 Add to Order
MS-2117 .004" +-.0003" 6.00" 60" $27.58 Add to Order
MS-2215 .004" +-.0003" 6.00" 100" $39.40 Add to Order
MS-3332 .004" +-.0003" 12" 120" $80.18 Add to Order
MS-607 .005" -0.0004 .500" 600" $194.70 Add to Order
MS-838 .005" -0.0004 2.00" 180" $196.34 Add to Order
MS-815 .005" -0.0004 4.00" 120" $194.70 Add to Order
MS-3354 .005" +-.0004" 6.00" 60" $28.68 Add to Order
MS-3302 .005" +-.0004" 6.00" 100" $43.32 Add to Order
MS-10201 .005" +-.0004" 12" 12" $79.98 - 5 pcs Add to Order
MS-3301 .005" +-.0004" 12" 120" $89.64 Add to Order
MS-3292 .006" +-.0004" 6.00" 60" $77.46 Add to Order
MS-3309 .006" +-.0004" 6.00" 100" $50.86 Add to Order
MS-3371 .006" +-.0004" 12" 120" $101.44 Add to Order
MS-3421 .007" +-.0005" 6.00" 60" $36.00 Add to Order
MS-3341 .007" +-.0005" 6.00" 100" $58.68 Add to Order
MS-3403 .008" +-.0005" 6.00" 60" $40.58 Add to Order
MS-3402 .008" +-.0005" 6.00" 100" $67.98 Add to Order
MS-2720 .008" +-.0005" 12" 120" $135.04 Add to Order
MS-2719 .009" +-.0005" 6.00" 60" $45.68 Add to Order
MS-2718 .009" +-.0005" 6.00" 100" $116.16 Add to Order
MS-1048 .010" -0.001 .500" 600" $196.34 Add to Order
MS-1003 .010" -0.001 1.00" 420" $196.34 Add to Order
MS-10120 .010" -0.001 2.00" 36" $22.10 Add to Order
MS-835 .010" -0.001 2.00" 180" $196.34 Add to Order
MS-10148 .010" -0.001 4.00" 36" $35.70 Add to Order
MS-169 .010" -0.001 4.00" 120" $196.34 Add to Order
MS-10184 .010" +-.0007" 6.00" 36" $51.00 Add to Order
MS-2899 .010" +-.0007" 6.00" 60" $78.00 Add to Order
MS-3112 .010" +-.0007" 6.00" 100" $67.34 Add to Order
MS-10121 .012" -0.001 2.00" 36" $23.16 Add to Order
MS-10149 .012" -0.001 4.00" 36" $37.42 Add to Order
MS-733 .012" +-.001" 6.00" 25" $52.46 Add to Order
MS-10185 .012" +-.001" 6.00" 36" $53.44 Add to Order
MS-3075 .012" +-.001" 6.00" 60" $51.02 Add to Order
MS-3401 .012" +-.001" 6.00" 100" $78.04 Add to Order
MS-3400 .012" +-.001" 12" 120" $302.20 Add to Order
MS-993 .015" -0.001 1.00" 420" $196.34 Add to Order
MS-723 .015" +-.001" 6.00" 25" $58.10 Add to Order
MS-3399 .015" +-.001" 6.00" 60" $56.34 Add to Order
MS-3390 .015" +-.001" 6.00" 100" $91.56 Add to Order
MS-3397 .015" +-.001" 12" 120" $214.78 Add to Order
MS-636 .016" +-.002" .750" 12" $2.48 Add to Order
MS-10122 .016" -0.001 2.00" 36" $26.96 Add to Order
MS-10150 .016" -0.001 4.00" 36" $43.56 Add to Order
MS-10186 .016" -0.001 6.00" 36" $62.24 Add to Order
MS-3405 .018" +-.002" 6.00" 100" $193.36 Add to Order
MS-1049 .020" -0.0015 .500" 600" $203.70 Add to Order
MS-10123 .020" -0.001 2.00" 36" $33.56 Add to Order
MS-799 .020" -0.0015 2.00" 240" $292.04 Add to Order
MS-722 .020" +-.002" 6.00" 25" $69.14 Add to Order
MS-3395 .020" +-.002" 6.00" 60" $131.94 Add to Order
MS-776 .020" +-.002" 6.00" 100" $95.04 Add to Order
MS-775 .020" +-.002" 12" 120" $213.52 Add to Order
MS-10124 .025" -0.001 2.00" 36" $39.68 Add to Order
MS-10152 .025" -0.0015 4.00" 36" $64.10 Add to Order
MS-721 .025" +-.001" 6.00" 25" $72.60 Add to Order
MS-766 .025" +-.001" 6.00" 60" $109.98 Add to Order
MS-773 .025" +-.001" 6.00" 100" $88.34 Add to Order
MS-771 .031" +-.0015" 6.00" 100" $176.24 Add to Order
MS-720 .031" +-.001" 6.00" 25" $88.24 Add to Order
MS-781 .031" +-.0015" 6.00" 60" $163.06 Add to Order
MS-999 .032" -0.002 1.00" 240" $203.70 Add to Order
MS-10125 .032" -0.001 2.00" 36" $50.90 Add to Order
MS-10126 .040" - 2.00" 36" $62.90 Add to Order
MS-10127 .050" - 2.00" 36" $75.94 Add to Order
MS-10128 .062" - 2.00" 36" $94.22 Add to Order
MS-10129 .080" - 2.00" 36" $109.12 Add to Order
MBS-8928 .094" +/-.004 .250" 12" $9.68 Add to Order
MBS-8929 .094" +/-.004 .500" 12" $13.58 Add to Order
MBS-8930 .094" +/-.004 .750" 12" $24.94 Add to Order
MBS-8931 .094" +/-.004 1.00" 12" $28.60 Add to Order
MBS-8932 .094" +/-.004 2.00" 12" $52.86 Add to Order
MS-10130 .094" - 2.00" 36" $123.32 Add to Order
MS-10131 .125" - 2.00" 36" $147.36 Add to Order
MS-10132 .188" - 2.00" 36" $211.44 Add to Order
MS-10133 .250" - 2.00" 36" $332.12 Add to Order
MS-10134 .500" - 2.00" 36" $896.94 Add to Order
MS-10135 .750" - 2.00" 36" $1,265.18 Add to Order
MS-10136 1.00" - 2.00" 36" $1,639.76 Add to Order
Rev. 10-23, 05-23, 10-22, 09-22



260 Brass Sheets

 - 1/2 Hard,  - 1/4 Hard, ASTM B36M

Part # Thickness Thickness Tolerance Width Length Hardness Price Each Order Online
Brushed #4 Satin Finished
MS-914 .032" +-0.005" 12.00" 12.00" $89.68 Add to Order
MS-913 .032" +-0.005" 12.00" 24.00" $162.40 Add to Order
MS-887 .032" +-0.005" 24.00" 24.00" $298.92 Add to Order
MS-926 .040" +-0.005" 12.00" 12.00" $114.54 Add to Order
MS-901 .040" +-0.005" 12.00" 24.00" $195.72 Add to Order
MS-877 .040" +-0.005" 24.00" 24.00" $369.86 Add to Order
MS-875 .062" +-0.005" 12.00" 12.00" $158.72 Add to Order
MS-874 .062" +-0.005" 12.00" 24.00" $282.10 Add to Order
MS-873 .062" +-0.005" 24.00" 24.00" $534.60 Add to Order
MS-872 .080" +-0.008" 12.00" 12.00" $258.48 Add to Order
MS-863 .080" +-0.008" 12.00" 24.00" $471.84 Add to Order
MS-870 .080" +-0.008" 24.00" 24.00" $925.16 Add to Order
MS-878 .125" +-0.008" 12.00" 12.00" $381.12 Add to Order
MS-868 .125" +-0.008" 12.00" 24.00" $702.80 Add to Order
MS-867 .125" +-0.008" 24.00" 24.00" $1,351.52 Add to Order
MS-866 .187" +-0.008" 12.00" 12.00" $607.04 Add to Order
MS-865 .187" +-0.008" 12.00" 24.00" $1,115.00 Add to Order
MS-885 .187" +-0.008" 24.00" 24.00" $2,144.24 Add to Order
Mirror Like (#8) Finish
MS-869 .032" +-0.005" 12.00" 12.00" $149.56 Add to Order
MS-871 .032" +-0.005" 12.00" 24.00" $252.78 Add to Order
MS-893 .032" +-0.005" 24.00" 24.00" $475.88 Add to Order
MS-892 .040" +-0.005" 12.00" 12.00" $166.70 Add to Order
MS-457 .040" +-0.005" 12.00" 24.00" $285.22 Add to Order
MS-890 .040" +-0.005" 24.00" 24.00" $528.88 Add to Order
MS-587 .062" +-0.005" 12.00" 12.00" $195.82 Add to Order
MS-888 .062" +-0.005" 12.00" 24.00" $355.64 Add to Order
MS-879 .062" +-0.005" 24.00" 24.00" $683.94 Add to Order
MS-886 .080" +-0.008" 12.00" 12.00" $277.16 Add to Order
MS-894 .080" +-0.008" 12.00" 24.00" $482.00 Add to Order
MS-884 .080" +-0.008" 24.00" 24.00" $926.94 Add to Order
MS-883 .125" +-0.008" 12.00" 12.00" $398.34 Add to Order
MS-882 .125" +-0.008" 12.00" 24.00" $737.40 Add to Order
MS-881 .125" +-0.008" 24.00" 24.00" $1,418.08 Add to Order
MS-880 .187" +-0.008" 12.00" 12.00" $606.46 Add to Order
MS-974 .187" +-0.008" 12.00" 24.00" $1,139.72 Add to Order
MS-442 .187" +-0.008" 24.00" 24.00" $2,191.76 Add to Order
Reflective Finish
MS-917 .050" +-0.006" 12.00" 24.00" $198.62 Add to Order
MS-916 .050" +-0.006" 24.00" 48.00" $642.58 Add to Order
Unpolished Finish
MS-970 .005" +-0.001" 4.00" 10.00" $64.26-6 Pcs Add to Order
MS-969 .010" +-0.001" 4.00" 10.00" $38.26 -6 Pcs Add to Order
MS-975 .010" +-0.0015" 12.00" 12.00" $34.00 Add to Order
MS-976 .010" +-0.0015" 12.00" 24.00" $57.80 Add to Order
MS-992 .010" +-0.0015" 24.00" 24.00" $101.98 Add to Order
MS-965 .012" +-0.002" 12.00" 12.00" $35.64 Add to Order
MS-980 .012" +-0.002" 12.00" 24.00" $60.58 Add to Order
MS-978 .012" +-0.002" 24.00" 24.00" $106.90 Add to Order
MS-960 .015" +-0.001" 4.00" 10.00" $57.46 - 6 Pcs Add to Order
MS-631 .016" +-.002" .500" 12.00" $18.90-15 Pcs Add to Order
MS-623 .016" +-.002" 1.00" 12.00" $26.40-10 Pcs Add to Order
MS-964 .016" +-0.0025" 12.00" 12.00" $41.48 Add to Order
MS-966 .016" +-0.0025" 12.00" 24.00" $70.52 Add to Order
MS-941 .016" +-0.0025" 24.00" 24.00" $124.46 Add to Order
MS-963 .020" +-0.0035" 12.00" 12.00" $52.93 Add to Order
MS-938 .020" +-0.0035" 12.00" 24.00" $87.78 Add to Order
MS-928 .020" +-0.0035" 24.00" 24.00" $154.90 Add to Order
MS-630 .025" +-.002" .500" 12.00" $21.20 - 10 Pcs Add to Order
MS-622 .025" +-.002" 1.00" 12.00" $20.64 - 6 Pcs Add to Order
MS-962 .025" +-0.0035" 12.00" 12.00" $57.80 Add to Order
MS-933 .025" +-0.0035" 12.00" 24.00" $103.78 Add to Order
MS-931 .025" +-0.0035" 24.00" 24.00" $183.14 Add to Order
MS-621 .032" +-.002" .500" 12.00" $19.80-10 Pcs Add to Order
MS-813 .032" +-.002" 1.00" 12.00" $17.40 - 5 Pcs Add to Order
MS-961 .032" +-0.004" 12.00" 12.00" $78.30 Add to Order
MS-934 .032" +-0.004" 12.00" 24.00" $133.12 Add to Order
MS-958 .032" +-0.004" 24.00" 24.00" $234.92 Add to Order
MS-967 .032" +-0.001" 4.00" 10.00" $49.90 - 3 Pcs Add to Order
MS-983 .040" +-0.005" 12.00" 12.00" $97.04 Add to Order
MS-955 .040" +-0.005" 12.00" 24.00" $164.48 Add to Order
MS-953 .040" +-0.005" 24.00" 24.00" $290.26 Add to Order
MS-985 .050" +-0.006" 12.00" 12.00" $116.84 Add to Order
MS-948 .050" +-0.006" 24.00" 24.00" $350.50 Add to Order
MS-632 .064" +-.002" .250" 12.00" $2.34 Add to Order
MS-628 .064" +-.002" .500" 12.00" $14.40 - 4 Pcs Add to Order
MS-968 .064" +-0.006" 12.00" 12.00" $144.42 Add to Order
MS-946 .064" +-0.006" 12.00" 24.00" $231.94 Add to Order
MS-929 .064" +-0.006" 24.00" 24.00" $434.88 Add to Order
MS-977 .064" +-0.006" 24.00" 48.00" $797.28 Add to Order
MS-990 .080" +-0.007" 12.00" 12.00" $159.48 Add to Order
MS-1038 .080" +-0.007" 12.00" 24.00" $268.60 Add to Order
MS-820 .080" +-0.007" 24.00" 24.00" $503.64 Add to Order
MS-819 .080" +-0.007" 24.00" 48.00" $923.34 Add to Order
MS-989 .093" +-0.007" 12.00" 12.00" $180.24 Add to Order
MS-817 .093" +-0.007" 12.00" 24.00" $303.56 Add to Order
MS-864 .093" +-0.007" 24.00" 24.00" $569.18 Add to Order
MS-912 .093" +-0.007" 24.00" 48.00" $1,043.50 Add to Order
MS-988 .125" +-0.007" 12.00" 12.00" $215.38 Add to Order
MS-908 .125" +-0.007" 12.00" 24.00" $362.72 Add to Order
MS-906 .125" +-0.007" 24.00" 24.00" $680.12 Add to Order
MS-905 .125" +-0.007" 24.00" 48.00" $1,246.88 Add to Order
MS-987 .187" +-0.008" 12.00" 12.00" $309.04 Add to Order
MS-895 .187" +-0.008" 12.00" 24.00" $520.48 Add to Order
MS-910 .187" +-0.008" 24.00" 24.00" $975.90 Add to Order
MS-900 .187" +-0.008" 24.00" 48.00" $1,789.16 Add to Order
MS-3070 .250" +-0.014" 12.00" 24.00" $551.88 Add to Order
MS-3092 .250" +-0.014" 24.00" 24.00" $1,188.50 Add to Order
Rev. 10-23, 05-23, 10-22, 09-22
<<
