Vibration Resistant Serrated Flange Head Bolts
Zinc Plated Steel, Grade 5, Fully Threaded, RH Threads, SAE J429
| Vibration Resistant Serrated Flange Head Bolts | ||||||||
| Part # | Thread Size | Overall Length | Flange Diameter | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-162 | 6-32 | .250" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-163 | 6-32 | .375" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-164 | 6-32 | .500" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-165 | 6-32 | .625" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-166 | 6-32 | .750" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-167 | 6-32 | 1.00" | .359" | 1/4" | 5/32" | 100 | $27.38 | Add to Order |
| Bolt-168 | 8-32 | .250" | .375" | 1/4" | 3/16" | 100 | $27.38 | Add to Order |
| Bolt-169 | 8-32 | .375" | .375" | 1/4" | 3/16" | 100 | $27.38 | Add to Order |
| Bolt-170 | 8-32 | .500" | .375" | 1/4" | 3/16" | 100 | $36.54 | Add to Order |
| Bolt-171 | 8-32 | .625" | .375" | 1/4" | 3/16" | 100 | $36.54 | Add to Order |
| Bolt-172 | 8-32 | .750" | .375" | 1/4" | 3/16" | 100 | $36.54 | Add to Order |
| Bolt-173 | 8-32 | 1.00" | .375" | 1/4" | 3/16" | 100 | $36.54 | Add to Order |
| Bolt-174 | 10-24 | .375" | .453" | 5/16" | 7/32" | 100 | $11.80 | Add to Order |
| Bolt-175 | 10-24 | .500" | .453" | 5/16" | 7/32" | 100 | $12.75 | Add to Order |
| Bolt-176 | 10-24 | .625" | .453" | 5/16" | 7/32" | 100 | $36.54 | Add to Order |
| Bolt-177 | 10-24 | .750" | .453" | 5/16" | 7/32" | 100 | $14.72 | Add to Order |
| Bolt-178 | 10-24 | 1.00" | .453" | 5/16" | 7/32" | 100 | $45.61 | Add to Order |
| Bolt-179 | 10-32 | .375" | .453" | 5/16" | 7/32" | 100 | $27.43 | Add to Order |
| Bolt-180 | 10-32 | .500" | .453" | 5/16" | 7/32" | 100 | $36.50 | Add to Order |
| Bolt-181 | 10-32 | .625" | .453" | 5/16" | 7/32" | 100 | $15.92 | Add to Order |
| Bolt-182 | 10-32 | .750" | .453" | 5/16" | 7/32" | 100 | $45.70 | Add to Order |
| Bolt-183 | 10-32 | 1.00" | .453" | 5/16" | 7/32" | 100 | $45.61 | Add to Order |
| Bolt-184 | 1/4"-20 | .375" | .562" | 3/8" | 9/32" | 100 | $44.98 | Add to Order |
| Bolt-185 | 1/4"-20 | .500" | .562" | 3/8" | 9/32" | 100 | $35.13 | Add to Order |
| Bolt-186 | 1/4"-20 | .625" | .562" | 3/8" | 9/32" | 100 | $42.00 | Add to Order |
| Bolt-187 | 1/4"-20 | .750" | .562" | 3/8" | 9/32" | 100 | $36.20 | Add to Order |
| Bolt-188 | 1/4"-20 | .875" | .562" | 3/8" | 9/32" | 100 | $29.04 | Add to Order |
| Bolt-189 | 1/4"-20 | 1.00" | .562" | 3/8" | 9/32" | 50 | $28.39 | Add to Order |
| Bolt-190 | 1/4"-20 | 1.25" | .562" | 3/8" | 9/32" | 50 | $26.26 | Add to Order |
| Bolt-191 | 1/4"-20 | 1.50" | .562" | 3/8" | 9/32" | 50 | $31.50 | Add to Order |
| Bolt-192 | 1/4"-20 | 1.75" | .562" | 3/8" | 9/32" | 50 | $31.50 | Add to Order |
| Bolt-193 | 1/4"-20 | 2.00" | .562" | 3/8" | 9/32" | 50 | $33.14 | Add to Order |
| Bolt-194 | 1/4"-20 | 2.25" | .562" | 3/8" | 9/32" | 50 | $42.97 | Add to Order |
| Bolt-195 | 1/4"-20 | 2.50" | .562" | 3/8" | 9/32" | 25 | $24.49 | Add to Order |
| Bolt-196 | 1/4"-20 | 2.75" | .562" | 3/8" | 9/32" | 25 | $29.09 | Add to Order |
| Bolt-197 | 1/4"-20 | 3.00" | .562" | 3/8" | 9/32" | 25 | $30.07 | Add to Order |
| Bolt-198 | 5/16"-18 | .500" | .687" | 1/2" | 21/64" | 50 | $28.64 | Add to Order |
| Bolt-199 | 5/16"-18 | .625" | .687" | 1/2" | 21/64" | 50 | $37.99 | Add to Order |
| Bolt-200 | 5/16"-18 | .750" | .687" | 1/2" | 21/64" | 50 | $29.40 | Add to Order |
| Bolt-201 | 5/16"-18 | .875" | .687" | 1/2" | 21/64" | 50 | $36.20 | Add to Order |
| Bolt-202 | 5/16"-18 | 1.00" | .687" | 1/2" | 21/64" | 50 | $33.31 | Add to Order |
| Bolt-203 | 5/16"-18 | 1.25" | .687" | 1/2" | 21/64" | 50 | $40.36 | Add to Order |
| Bolt-204 | 5/16"-18 | 1.50" | .687" | 1/2" | 21/64" | 25 | $26.65 | Add to Order |
| Bolt-205 | 5/16"-18 | 1.75" | .687" | 1/2" | 21/64" | 25 | $23.86 | Add to Order |
| Bolt-206 | 5/16"-18 | 2.00" | .687" | 1/2" | 21/64" | 25 | $27.51 | Add to Order |
| Bolt-207 | 5/16"-18 | 2.50" | .687" | 1/2" | 21/64" | 25 | $32.68 | Add to Order |
| Bolt-208 | 5/16"-18 | 3.00" | .687" | 1/2" | 21/64" | 20 | $29.82 | Add to Order |
| Bolt-209 | 3/8"-16 | .500" | .812" | 9/16" | 25/64" | 25 | $23.86 | Add to Order |
| Bolt-210 | 3/8"-16 | .625" | .812" | 9/16" | 25/64" | 25 | $30.60 | Add to Order |
| Bolt-211 | 3/8"-16 | .750" | .812" | 9/16" | 25/64" | 25 | $33.33 | Add to Order |
| Bolt-212 | 3/8"-16 | .875" | .812" | 9/16" | 25/64" | 25 | $33.52 | Add to Order |
| Bolt-213 | 3/8"-16 | 1.00" | .812" | 9/16" | 25/64" | 25 | $35.01 | Add to Order |
| Bolt-214 | 3/8"-16 | 1.25" | .812" | 9/16" | 25/64" | 25 | $37.63 | Add to Order |
| Bolt-215 | 3/8"-16 | 1.50" | .812" | 9/16" | 25/64" | 25 | $48.20 | Add to Order |
| Bolt-216 | 3/8"-16 | 1.75" | .812" | 9/16" | 25/64" | 20 | $38.26 | Add to Order |
| Bolt-217 | 3/8"-16 | 2.00" | .812" | 9/16" | 25/64" | 20 | $39.77 | Add to Order |
| Bolt-218 | 3/8"-16 | 2.25" | .812" | 9/16" | 25/64" | 20 | $39.90 | Add to Order |
| Bolt-219 | 3/8"-16 | 2.50" | .812" | 9/16" | 25/64" | 20 | $39.98 | Add to Order |
| Bolt-220 | 3/8"-16 | 2.75" | .812" | 9/16" | 25/64" | 20 | $46.20 | Add to Order |
| Bolt-221 | 3/8"-16 | 3.00" | .812" | 9/16" | 25/64" | 10 | $26.08 | Add to Order |
| Bolt-222 | 7/16"-14 | 1.00" | .937" | 5/8" | 15/32" | 20 | $34.27 | Add to Order |
| Bolt-223 | 7/16"-14 | 1.25" | .937" | 5/8" | 15/32" | 20 | $36.41 | Add to Order |
| Bolt-224 | 7/16"-14 | 1.50" | .937" | 5/8" | 15/32" | 20 | $44.73 | Add to Order |
| Bolt-225 | 1/2"-13 | .750" | 1.078" | 3/4" | 33/64" | 10 | $24.36 | Add to Order |
| Bolt-226 | 1/2"-13 | 1.00" | 1.078" | 3/4" | 33/64" | 10 | $26.73 | Add to Order |
| Bolt-227 | 1/2"-13 | 1.25" | 1.078" | 3/4" | 33/64" | 10 | $27.85 | Add to Order |
| Bolt-228 | 1/2"-13 | 1.50" | 1.078" | 3/4" | 33/64" | 10 | $34.84 | Add to Order |
| Bolt-229 | 1/2"-13 | 1.75" | 1.078" | 3/4" | 33/64" | 10 | $27.83 | Add to Order |
| Bolt-230 | 1/2"-13 | 2.00" | 1.078" | 3/4" | 33/64" | 10 | $39.82 | Add to Order |
| Bolt-231 | 1/2"-13 | 2.50" | 1.078" | 3/4" | 33/64" | 5 | $23.69 | Add to Order |
| Bolt-232 | 1/2"-13 | 3.00" | 1.078" | 3/4" | 33/64" | 5 | $28.50 | Add to Order |
| Bolt-233 | 5/8"-11 | 1.50" | 1.328" | 15/16" | 5/8" | 5 | $35.28 | Add to Order |
| Bolt-234 | 5/8"-11 | 1.75" | 1.328" | 15/16" | 5/8" | 5 | $33.39 | Add to Order |
| Bolt-235 | 5/8"-11 | 2.00" | 1.328" | 15/16" | 5/8" | 5 | $38.12 | Add to Order |
| Rev. 08-23, 04-23, 11-22, 03-22 | ||||||||
