Metric DIN 931 Zinc Plated Steel Hex Head Bolts
Class 8.8, Right Hand Threads, DIN 931
Metric Medium Strength Zinc Plated Steel Hex Head Bolts
| Metric Medium Strength Zinc Plated Steel Hex Head Bolts, Partial Threads | ||||||||
| Part # | Thread Size | Partial Thread | Overall Length | Head Width | Head Height | Pkg. Qty | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| Bolt-2413 | M4 x 0.7 | 13 to 18 | 45mm | 7mm | 2.8mm | 100 | $39.06 | Add to Order |
| Bolt-2414 | M4 x 0.7 | 13 to 18 | 50mm | 7mm | 2.8mm | 100 | $39.94 | Add to Order |
| Bolt-2430 | M5 x 0.8 | 16 to 20 | 65mm | 8mm | 3.5mm | 50 | $58.25 | Add to Order |
| Bolt-2431 | M5 x 0.8 | 16 to 20 | 70mm | 8mm | 3.5mm | 50 | $47.71 | Add to Order |
| Bolt-2432 | M5 x 0.8 | 16 to 20 | 80mm | 8mm | 3.5mm | 50 | $56.15 | Add to Order |
| Bolt-2462B | M6 x 1 | 18 to 23 | 30mm | 10mm | 4mm | 100 | $8.44 | Add to Order |
| Bolt-2462C | M6 x 1 | 18 to 23 | 40mm | 10mm | 4mm | 100 | $9.97 | Add to Order |
| Bolt-2462D | M6 x 1 | 18 to 23 | 45mm | 10mm | 4mm | 100 | $15.55 | Add to Order |
| Bolt-2462E | M6 x 1 | 18 to 23 | 50mm | 10mm | 4mm | 100 | $16.92 | Add to Order |
| Bolt-2449 | M6 x 1 | 18 to 23 | 55mm | 10mm | 4mm | 50 | $36.74 | Add to Order |
| Bolt-2451 | M6 x 1 | 18 to 23 | 60mm | 10mm | 4mm | 50 | $14.17 | Add to Order |
| Bolt-2453 | M6 x 1 | 18 to 23 | 65mm | 10mm | 4mm | 25 | $24.41 | Add to Order |
| Bolt-2455 | M6 x 1 | 18 to 23 | 70mm | 10mm | 4mm | 25 | $20.47 | Add to Order |
| Bolt-2457 | M6 x 1 | 18 to 23 | 80mm | 10mm | 4mm | 50 | $52.92 | Add to Order |
| Bolt-2459 | M6 x 1 | 18 to 23 | 90mm | 10mm | 4mm | 25 | $35.99 | Add to Order |
| Bolt-2461 | M6 x 1 | 18 to 23 | 100mm | 10mm | 4mm | 25 | $36.71 | Add to Order |
| Bolt-2462 | M6 x 1 | 18 to 23 | 110mm | 10mm | 4mm | 20 | $30.41 | Add to Order |
| Bolt-2488 | M8 x 1.25 | 22 to 29 | 55mm | 13mm | 5.3mm | 25 | $26.24 | Add to Order |
| Bolt-2490 | M8 x 1.25 | 22 to 29 | 60mm | 13mm | 5.3mm | 50 | $13.46 | Add to Order |
| Bolt-2492 | M8 x 1.25 | 22 to 29 | 65mm | 13mm | 5.3mm | 25 | $28.53 | Add to Order |
| Bolt-2494 | M8 x 1.25 | 22 to 29 | 70mm | 13mm | 5.3mm | 25 | $30.56 | Add to Order |
| Bolt-2495 | M8 x 1.25 | 22 to 29 | 75mm | 13mm | 5.3mm | 25 | $41.65 | Add to Order |
| Bolt-2497 | M8 x 1.25 | 22 to 29 | 80mm | 13mm | 5.3mm | 25 | $33.93 | Add to Order |
| Bolt-2498 | M8 x 1.25 | 22 to 29 | 85mm | 13mm | 5.3mm | 20 | $41.79 | Add to Order |
| Bolt-2500 | M8 x 1.25 | 22 to 29 | 90mm | 13mm | 5.3mm | 10 | $19.17 | Add to Order |
| Bolt-2502 | M8 x 1.25 | 22 to 29 | 100mm | 13mm | 5.3mm | 20 | $17.82 | Add to Order |
| Bolt-2503 | M8 x 1.25 | 22 to 29 | 110mm | 13mm | 5.3mm | 20 | $12.29 | Add to Order |
| Bolt-2504 | M8 x 1.25 | 22 to 29 | 120mm | 13mm | 5.3mm | 10 | $41.64 | Add to Order |
| Bolt-2505 | M8 x 1.25 | 22 to 29 | 130mm | 13mm | 5.3mm | 10 | $43.11 | Add to Order |
| Bolt-2506 | M8 x 1.25 | 22 to 29 | 140mm | 13mm | 5.3mm | 10 | $43.20 | Add to Order |
| Bolt-2507 | M8 x 1.25 | 22 to 29 | 150mm | 13mm | 5.3mm | 10 | $43.76 | Add to Order |
| Bolt-2508 | M8 x 1.25 | 22 to 29 | 160mm | 13mm | 5.3mm | 10 | $44.18 | Add to Order |
| Bolt-2509 | M8 x 1.25 | 22 to 29 | 180mm | 13mm | 5.3mm | 10 | $48.04 | Add to Order |
| Bolt-2561B | M10 x 1.5 | 26 to 34 | 40mm | 17mm | 6.4mm | 50 | $18.04 | Add to Order |
| Bolt-2561C | M10 x 1.5 | 26 to 34 | 45mm | 17mm | 6.4mm | 50 | $18.38 | Add to Order |
| Bolt-2561D | M10 x 1.5 | 26 to 34 | 50mm | 17mm | 6.4mm | 50 | $19.89 | Add to Order |
| Bolt-2539 | M10 x 1.5 | 26 to 34 | 55mm | 17mm | 6.4mm | 50 | $21.20 | Add to Order |
| Bolt-2541 | M10 x 1.5 | 26 to 34 | 60mm | 17mm | 6.4mm | 50 | $22.68 | Add to Order |
| Bolt-2543 | M10 x 1.5 | 26 to 34 | 65mm | 17mm | 6.4mm | 20 | $40.36 | Add to Order |
| Bolt-2545 | M10 x 1.5 | 26 to 34 | 70mm | 17mm | 6.4mm | 25 | $12.85 | Add to Order |
| Bolt-2546 | M10 x 1.5 | 26 to 34 | 75mm | 17mm | 6.4mm | 25 | $25.88 | Add to Order |
| Bolt-2548 | M10 x 1.5 | 26 to 34 | 80mm | 17mm | 6.4mm | 25 | $14.36 | Add to Order |
| Bolt-2550 | M10 x 1.5 | 26 to 34 | 90mm | 17mm | 6.4mm | 10 | $26.51 | Add to Order |
| Bolt-2552 | M10 x 1.5 | 26 to 34 | 100mm | 17mm | 6.4mm | 25 | $20.84 | Add to Order |
| Bolt-2553 | M10 x 1.5 | 26 to 34 | 110mm | 17mm | 6.4mm | 10 | $39.40 | Add to Order |
| Bolt-2555 | M10 x 1.5 | 26 to 34 | 120mm | 17mm | 6.4mm | 10 | $14.00 | Add to Order |
| Bolt-2556 | M10 x 1.5 | 26 to 34 | 130mm | 17mm | 6.4mm | 10 | $52.84 | Add to Order |
| Bolt-2557 | M10 x 1.5 | 26 to 34 | 140mm | 17mm | 6.4mm | 5 | $27.11 | Add to Order |
| Bolt-2558 | M10 x 1.5 | 26 to 34 | 150mm | 17mm | 6.4mm | 10 | $66.07 | Add to Order |
| Bolt-2559 | M10 x 1.5 | 26 to 34 | 160mm | 17mm | 6.4mm | 10 | $65.94 | Add to Order |
| Bolt-2560 | M10 x 1.5 | 26 to 34 | 180mm | 17mm | 6.4mm | 5 | $36.75 | Add to Order |
| Bolt-2561 | M10 x 1.5 | 26 to 34 | 200mm | 17mm | 6.4mm | 5 | $35.47 | Add to Order |
| Bolt-2611 | M12 x 1.75 | 30 to 39 | 60mm | 19mm | 7.5mm | 25 | $16.22 | Add to Order |
| Bolt-2612 | M12 x 1.75 | 30 to 39 | 65mm | 19mm | 7.5mm | 25 | $20.57 | Add to Order |
| Bolt-2614 | M12 x 1.75 | 30 to 39 | 70mm | 19mm | 7.5mm | 50 | $39.60 | Add to Order |
| Bolt-2616 | M12 x 1.75 | 30 to 39 | 75mm | 19mm | 7.5mm | 25 | $18.22 | Add to Order |
| Bolt-2618 | M12 x 1.75 | 30 to 39 | 80mm | 19mm | 7.5mm | 25 | $21.20 | Add to Order |
| Bolt-2620 | M12 x 1.75 | 30 to 39 | 90mm | 19mm | 7.5mm | 10 | $36.90 | Add to Order |
| Bolt-2622 | M12 x 1.75 | 30 to 39 | 100mm | 19mm | 7.5mm | 25 | $36.47 | Add to Order |
| Bolt-2623 | M12 x 1.75 | 30 to 39 | 110mm | 19mm | 7.5mm | 10 | $28.62 | Add to Order |
| Bolt-2624 | M12 x 1.75 | 30 to 39 | 120mm | 19mm | 7.5mm | 10 | $28.49 | Add to Order |
| Bolt-2625 | M12 x 1.75 | 30 to 39 | 130mm | 19mm | 7.5mm | 25 | $22.42 | Add to Order |
| Bolt-2626 | M12 x 1.75 | 30 to 39 | 140mm | 19mm | 7.5mm | 5 | $39.48 | Add to Order |
| Bolt-2627 | M12 x 1.75 | 30 to 39 | 160mm | 19mm | 7.5mm | 5 | $41.03 | Add to Order |
| Bolt-2628 | M12 x 1.75 | 30 to 39 | 180mm | 19mm | 7.5mm | 5 | $42.02 | Add to Order |
| Bolt-2629 | M12 x 1.75 | 30 to 39 | 200mm | 19mm | 7.5mm | 5 | $44.25 | Add to Order |
| Bolt-2679 | M14 x 2 | 34 to 44 | 60mm | 22mm | 8.8mm | 10 | $18.90 | Add to Order |
| Bolt-2680 | M14 x 2 | 34 to 44 | 65mm | 22mm | 8.8mm | 10 | $14.51 | Add to Order |
| Bolt-2682 | M14 x 2 | 34 to 44 | 70mm | 22mm | 8.8mm | 10 | $15.79 | Add to Order |
| Bolt-2683 | M14 x 2 | 34 to 44 | 75mm | 22mm | 8.8mm | 10 | $13.84 | Add to Order |
| Bolt-2685 | M14 x 2 | 34 to 44 | 80mm | 22mm | 8.8mm | 10 | $65.81 | Add to Order |
| Bolt-2686 | M14 x 2 | 34 to 44 | 90mm | 22mm | 8.8mm | 10 | $15.82 | Add to Order |
| Bolt-2687 | M14 x 2 | 34 to 44 | 100mm | 22mm | 8.8mm | 5 | $37.74 | Add to Order |
| Bolt-2688 | M14 x 2 | 34 to 44 | 120mm | 22mm | 8.8mm | 5 | $43.72 | Add to Order |
| Bolt-2689 | M14 x 2 | 34 to 44 | 130mm | 22mm | 8.8mm | 4 | $35.28 | Add to Order |
| Bolt-2690 | M14 x 2 | 34 to 44 | 140mm | 22mm | 8.8mm | 4 | $12.06 | Add to Order |
| Bolt-2691 | M14 x 2 | 34 to 44 | 150mm | 22mm | 8.8mm | 4 | $44.32 | Add to Order |
| Bolt-2692 | M14 x 2 | 34 to 44 | 160mm | 22mm | 8.8mm | 4 | $48.13 | Add to Order |
| Bolt-2693 | M14 x 2 | 34 to 44 | 180mm | 22mm | 8.8mm | 4 | $38.72 | Add to Order |
| Bolt-2722 | M16 x 2 | 38 to 48 | 60mm | 24mm | 10mm | 10 | $50.13 | Add to Order |
| Bolt-2724 | M16 x 2 | 38 to 48 | 65mm | 24mm | 10mm | 10 | $43.09 | Add to Order |
| Bolt-2726 | M16 x 2 | 38 to 48 | 70mm | 24mm | 10mm | 10 | $25.92 | Add to Order |
| Bolt-2727 | M16 x 2 | 38 to 48 | 75mm | 24mm | 10mm | 10 | $51.91 | Add to Order |
| Bolt-2729 | M16 x 2 | 38 to 48 | 80mm | 24mm | 10mm | 10 | $19.62 | Add to Order |
| Bolt-2731 | M16 x 2 | 38 to 48 | 90mm | 24mm | 10mm | 5 | $14.15 | Add to Order |
| Bolt-2733 | M16 x 2 | 38 to 48 | 100mm | 24mm | 10mm | 5 | $31.10 | Add to Order |
| Bolt-2734 | M16 x 2 | 38 to 48 | 110mm | 24mm | 10mm | 5 | $19.04 | Add to Order |
| Bolt-2736 | M16 x 2 | 38 to 48 | 120mm | 24mm | 10mm | 5 | $36.37 | Add to Order |
| Bolt-2737 | M16 x 2 | 38 to 48 | 130mm | 24mm | 10mm | 5 | $39.87 | Add to Order |
| Bolt-2738 | M16 x 2 | 38 to 48 | 140mm | 24mm | 10mm | 6 | $31.88 | Add to Order |
| Bolt-2739 | M16 x 2 | 38 to 48 | 150mm | 24mm | 10mm | 5 | $26.53 | Add to Order |
| Bolt-2740 | M16 x 2 | 38 to 48 | 160mm | 24mm | 10mm | 4 | $33.52 | Add to Order |
| Bolt-2741 | M16 x 2 | 38 to 48 | 200mm | 24mm | 10mm | 3 | $40.70 | Add to Order |
| Bolt-2774 | M20 x 2.5 | 46 to 59 | 60mm | 30mm | 12.5mm | 5 | $47.71 | Add to Order |
| Bolt-2775 | M20 x 2.5 | 46 to 59 | 65mm | 30mm | 12.5mm | 3 | $42.15 | Add to Order |
| Bolt-2776 | M20 x 2.5 | 46 to 59 | 70mm | 30mm | 12.5mm | 5 | $49.04 | Add to Order |
| Bolt-2777 | M20 x 2.5 | 46 to 59 | 75mm | 30mm | 12.5mm | 3 | $44.98 | Add to Order |
| Bolt-2779 | M20 x 2.5 | 46 to 59 | 80mm | 30mm | 12.5mm | 6 | $34.02 | Add to Order |
| Bolt-2780 | M20 x 2.5 | 46 to 59 | 90mm | 30mm | 12.5mm | 6 | $36.54 | Add to Order |
| Bolt-2782 | M20 x 2.5 | 46 to 59 | 100mm | 30mm | 12.5mm | 3 | $31.00 | Add to Order |
| Bolt-2783 | M20 x 2.5 | 46 to 59 | 110mm | 30mm | 12.5mm | 3 | $39.69 | Add to Order |
| Bolt-2784 | M20 x 2.5 | 46 to 59 | 120mm | 30mm | 12.5mm | 3 | $39.31 | Add to Order |
| Bolt-2785 | M20 x 2.5 | 46 to 59 | 140mm | 30mm | 12.5mm | 2 | $33.85 | Add to Order |
| Bolt-2786 | M20 x 2.5 | 46 to 59 | 150mm | 30mm | 12.5mm | 3 | $39.75 | Add to Order |
| Bolt-2787 | M20 x 2.5 | 46 to 59 | 160mm | 30mm | 12.5mm | 2 | $41.16 | Add to Order |
| Bolt-2788 | M20 x 2.5 | 46 to 59 | 180mm | 30mm | 12.5mm | 2 | $41.12 | Add to Order |
| Bolt-2789 | M20 x 2.5 | 46 to 59 | 200mm | 30mm | 12.5mm | 2 | $44.69 | Add to Order |
| Bolt-2807 | M24 x 3 | 54 to 69 | 70mm | 36mm | 15mm | 2 | $36.62 | Add to Order |
| Bolt-2808 | M24 x 3 | 54 to 69 | 75mm | 36mm | 15mm | 2 | $46.20 | Add to Order |
| Bolt-2810 | M24 x 3 | 54 to 69 | 80mm | 36mm | 15mm | 2 | $30.07 | Add to Order |
| Bolt-2811 | M24 x 3 | 54 to 69 | 90mm | 36mm | 15mm | 2 | $31.16 | Add to Order |
| Bolt-2812 | M24 x 3 | 54 to 69 | 100mm | 36mm | 15mm | 2 | $34.10 | Add to Order |
| Bolt-2813 | M24 x 3 | 54 to 69 | 110mm | 36mm | 15mm | 2 | $46.49 | Add to Order |
| Bolt-2814 | M24 x 3 | 54 to 69 | 120mm | 36mm | 15mm | 2 | $39.40 | Add to Order |
| Bolt-2815 | M24 x 3 | 54 to 69 | 130mm | 36mm | 15mm | 2 | $48.72 | Add to Order |
| Bolt-2816 | M24 x 3 | 54 to 69 | 140mm | 36mm | 15mm | 2 | $39.65 | Add to Order |
| Bolt-2817 | M24 x 3 | 54 to 69 | 150mm | 36mm | 15mm | 2 | $49.85 | Add to Order |
| Bolt-2818 | M24 x 3 | 54 to 69 | 160mm | 36mm | 15mm | 2 | $42.00 | Add to Order |
| Bolt-2819 | M24 x 3 | 54 to 69 | 180mm | 36mm | 15mm | 2 | $59.98 | Add to Order |
| Bolt-2820 | M24 x 3 | 54 to 69 | 200mm | 36mm | 15mm | 2 | $63.63 | Add to Order |
| Rev. 04-23, 11-22, 09-22, 07-22 | ||||||||
