Metric DIN 961 Zinc Plated Steel Hex Head Bolts
Class 8.8, Fully Threaded, Right Hand Threads, DIN 961
Metric Medium Strength Zinc Plated Steel Hex Head Screws
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Bolt-2510 | M8 x 1 | 10mm | 13mm | 5.3mm | 25 | $31.50 | Add to Order |
| Bolt-2511 | M8 x 1 | 12mm | 13mm | 5.3mm | 50 | $32.63 | Add to Order |
| Bolt-2512 | M8 x 1 | 16mm | 13mm | 5.3mm | 50 | $43.85 | Add to Order |
| Bolt-2513 | M8 x 1 | 20mm | 13mm | 5.3mm | 50 | $20.48 | Add to Order |
| Bolt-2514 | M8 x 1 | 25mm | 13mm | 5.3mm | 50 | $23.10 | Add to Order |
| Bolt-2515 | M8 x 1 | 30mm | 13mm | 5.3mm | 50 | $23.42 | Add to Order |
| Bolt-2516 | M8 x 1 | 35mm | 13mm | 5.3mm | 50 | $56.03 | Add to Order |
| Bolt-2517 | M8 x 1 | 40mm | 13mm | 5.3mm | 25 | $27.72 | Add to Order |
| Bolt-2519 | M8 x 1 | 45mm | 13mm | 5.3mm | 30 | $36.35 | Add to Order |
| Bolt-2521 | M8 x 1 | 50mm | 13mm | 5.3mm | 30 | $37.11 | Add to Order |
| Bolt-2562 | M10 x 1.25 | 16mm | 17mm | 6.4mm | 25 | $35.64 | Add to Order |
| Bolt-2563 | M10 x 1.25 | 20mm | 17mm | 6.4mm | 25 | $24.73 | Add to Order |
| Bolt-2564 | M10 x 1.25 | 25mm | 17mm | 6.4mm | 25 | $14.56 | Add to Order |
| Bolt-2565 | M10 x 1.25 | 30mm | 17mm | 6.4mm | 25 | $8.82 | Add to Order |
| Bolt-2566 | M10 x 1.25 | 35mm | 17mm | 6.4mm | 20 | $6.59 | Add to Order |
| Bolt-2568 | M10 x 1.25 | 40mm | 17mm | 6.4mm | 20 | $19.85 | Add to Order |
| Bolt-2570 | M10 x 1.25 | 45mm | 17mm | 6.4mm | 10 | $11.95 | Add to Order |
| Bolt-2572 | M10 x 1.25 | 50mm | 17mm | 6.4mm | 20 | $24.62 | Add to Order |
| Bolt-2575 | M10 x 1.25 | 60mm | 17mm | 6.4mm | 10 | $14.90 | Add to Order |
| Bolt-2585 | M10 x 1 | 16mm | 17mm | 6.4mm | 20 | $37.21 | Add to Order |
| Bolt-2586 | M10 x 1 | 20mm | 17mm | 6.4mm | 20 | $37.84 | Add to Order |
| Bolt-2587 | M10 x 1 | 25mm | 17mm | 6.4mm | 20 | $40.95 | Add to Order |
| Bolt-2588 | M10 x 1 | 30mm | 17mm | 6.4mm | 20 | $45.95 | Add to Order |
| Bolt-2589 | M10 x 1 | 35mm | 17mm | 6.4mm | 20 | $49.98 | Add to Order |
| Bolt-2590 | M10 x 1 | 40mm | 17mm | 6.4mm | 20 | $44.39 | Add to Order |
| Bolt-2592 | M10 x 1 | 45mm | 17mm | 6.4mm | 20 | $46.12 | Add to Order |
| Bolt-2594 | M10 x 1 | 50mm | 17mm | 6.4mm | 10 | $34.80 | Add to Order |
| Bolt-2596 | M10 x 1 | 60mm | 17mm | 6.4mm | 10 | $27.26 | Add to Order |
| Bolt-2630 | M12 x 1.5 | 16mm | 19mm | 7.5mm | 20 | $40.82 | Add to Order |
| Bolt-2631 | M12 x 1.5 | 20mm | 19mm | 7.5mm | 20 | $14.27 | Add to Order |
| Bolt-2632 | M12 x 1.5 | 25mm | 19mm | 7.5mm | 20 | $22.16 | Add to Order |
| Bolt-2633 | M12 x 1.5 | 30mm | 19mm | 7.5mm | 20 | $24.82 | Add to Order |
| Bolt-2634 | M12 x 1.5 | 35mm | 19mm | 7.5mm | 20 | $25.54 | Add to Order |
| Bolt-2635 | M12 x 1.5 | 40mm | 19mm | 7.5mm | 10 | $16.42 | Add to Order |
| Bolt-2637 | M12 x 1.5 | 45mm | 19mm | 7.5mm | 10 | $28.29 | Add to Order |
| Bolt-2638 | M12 x 1.5 | 50mm | 19mm | 7.5mm | 10 | $20.70 | Add to Order |
| Bolt-2641 | M12 x 1.5 | 60mm | 19mm | 7.5mm | 10 | $43.34 | Add to Order |
| Bolt-2649 | M12 x 1.25 | 20mm | 19mm | 7.5mm | 20 | $47.75 | Add to Order |
| Bolt-2650 | M12 x 1.25 | 25mm | 19mm | 7.5mm | 20 | $24.32 | Add to Order |
| Bolt-2651 | M12 x 1.25 | 30mm | 19mm | 7.5mm | 20 | $29.88 | Add to Order |
| Bolt-2652 | M12 x 1.25 | 35mm | 19mm | 7.5mm | 20 | $32.04 | Add to Order |
| Bolt-2653 | M12 x 1.25 | 40mm | 19mm | 7.5mm | 10 | $15.86 | Add to Order |
| Bolt-2655 | M12 x 1.25 | 45mm | 19mm | 7.5mm | 10 | $19.43 | Add to Order |
| Bolt-2657 | M12 x 1.25 | 50mm | 19mm | 7.5mm | 10 | $35.57 | Add to Order |
| Bolt-2660 | M12 x 1.25 | 60mm | 19mm | 7.5mm | 10 | $29.13 | Add to Order |
| Bolt-2694 | M14 x 1.5 | 20mm | 22mm | 8.8mm | 5 | $29.72 | Add to Order |
| Bolt-2695 | M14 x 1.5 | 25mm | 22mm | 8.8mm | 5 | $34.88 | Add to Order |
| Bolt-2696 | M14 x 1.5 | 30mm | 22mm | 8.8mm | 10 | $23.63 | Add to Order |
| Bolt-2697 | M14 x 1.5 | 35mm | 22mm | 8.8mm | 10 | $25.65 | Add to Order |
| Bolt-2698 | M14 x 1.5 | 40mm | 22mm | 8.8mm | 10 | $24.75 | Add to Order |
| Bolt-2699 | M14 x 1.5 | 45mm | 22mm | 8.8mm | 10 | $43.22 | Add to Order |
| Bolt-2701 | M14 x 1.5 | 50mm | 22mm | 8.8mm | 10 | $30.60 | Add to Order |
| Bolt-2703 | M14 x 1.5 | 55mm | 22mm | 8.8mm | 5 | $30.58 | Add to Order |
| Bolt-2704 | M14 x 1.5 | 60mm | 22mm | 8.8mm | 3 | $26.71 | Add to Order |
| Bolt-2742 | M16 x 1.5 | 20mm | 24mm | 10mm | 10 | $49.56 | Add to Order |
| Bolt-2743 | M16 x 1.5 | 25mm | 24mm | 10mm | 10 | $41.12 | Add to Order |
| Bolt-2744 | M16 x 1.5 | 30mm | 24mm | 10mm | 5 | $7.94 | Add to Order |
| Bolt-2745 | M16 x 1.5 | 35mm | 24mm | 10mm | 5 | $29.09 | Add to Order |
| Bolt-2746 | M16 x 1.5 | 40mm | 24mm | 10mm | 5 | $32.30 | Add to Order |
| Bolt-2747 | M16 x 1.5 | 50mm | 24mm | 10mm | 5 | $37.63 | Add to Order |
| Bolt-2749 | M16 x 1.5 | 60mm | 24mm | 10mm | 4 | $29.90 | Add to Order |
| Bolt-2762 | M18 x 1.5 | 30mm | 27mm | 11.5mm | 4 | $28.98 | Add to Order |
| Bolt-2763 | M18 x 1.5 | 40mm | 27mm | 11.5mm | 4 | $29.65 | Add to Order |
| Bolt-2764 | M18 x 1.5 | 50mm | 27mm | 11.5mm | 4 | $34.36 | Add to Order |
| Bolt-2765 | M18 x 1.5 | 60mm | 27mm | 11.5mm | 4 | $36.88 | Add to Order |
| Bolt-2790 | M20 x 2 | 50mm | 30mm | 12.5mm | 4 | $31.84 | Add to Order |
| Bolt-2791 | M20 x 2 | 60mm | 30mm | 12.5mm | 4 | $35.70 | Add to Order |
| Bolt-2792 | M20 x 1.5 | 30mm | 30mm | 12.5mm | 4 | $26.54 | Add to Order |
| Bolt-2793 | M20 x 1.5 | 40mm | 30mm | 12.5mm | 4 | $30.66 | Add to Order |
| Bolt-2794 | M20 x 1.5 | 50mm | 30mm | 12.5mm | 4 | $35.36 | Add to Order |
| Bolt-2795 | M20 x 1.5 | 60mm | 30mm | 12.5mm | 3 | $31.00 | Add to Order |
| Rev. 08-23, 04-23, 12-22, 11-22 | |||||||
