Bronze Bolts
Fully Threaded, RH Threads, ASME B18.2.1
| Bronze Bolts | |||||||
| Part # | Thread Size | Overall Length | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|
| Bolt-4811 | 1/4"-20 | .375" | 7/16" | 5/32" | 25 | $28.71 | Add to Order |
| Bolt-4812 | 1/4"-20 | .500" | 7/16" | 5/32" | 25 | $32.21 | Add to Order |
| Bolt-4813 | 1/4"-20 | .625" | 7/16" | 5/32" | 25 | $32.61 | Add to Order |
| Bolt-4814 | 1/4"-20 | .750" | 7/16" | 5/32" | 20 | $31.25 | Add to Order |
| Bolt-4815 | 1/4"-20 | 1.00" | 7/16" | 5/32" | 20 | $35.57 | Add to Order |
| Bolt-4816 | 1/4"-20 | 1.25" | 7/16" | 5/32" | 20 | $40.15 | Add to Order |
| Bolt-4817 | 1/4"-20 | 1.50" | 7/16" | 5/32" | 10 | $21.63 | Add to Order |
| Bolt-4818 | 1/4"-20 | 2.00" | 7/16" | 5/32" | 10 | $25.89 | Add to Order |
| Bolt-4819 | 1/4"-20 | 2.50" | 7/16" | 5/32" | 10 | $28.16 | Add to Order |
| Bolt-4820 | 1/4"-20 | 3.00" | 7/16" | 5/32" | 10 | $34.02 | Add to Order |
| Bolt-4821 | 5/16"-18 | .750" | 1/2" | 13/64" | 10 | $23.94 | Add to Order |
| Bolt-4822 | 5/16"-18 | 1.00" | 1/2" | 13/64" | 10 | $25.98 | Add to Order |
| Bolt-4823 | 5/16"-18 | 1.25" | 1/2" | 13/64" | 10 | $29.76 | Add to Order |
| Bolt-4824 | 5/16"-18 | 1.50" | 1/2" | 13/64" | 10 | $33.47 | Add to Order |
| Bolt-4825 | 5/16"-18 | 2.00" | 1/2" | 13/64" | 5 | $21.23 | Add to Order |
| Bolt-4826 | 3/8"-16 | .500" | 9/16" | 15/64" | 10 | $28.69 | Add to Order |
| Bolt-4827 | 3/8"-16 | .750" | 9/16" | 15/64" | 10 | $34.38 | Add to Order |
| Bolt-4828 | 3/8"-16 | 1.00" | 9/16" | 15/64" | 10 | $44.32 | Add to Order |
| Bolt-4829 | 3/8"-16 | 1.25" | 9/16" | 15/64" | 5 | $24.55 | Add to Order |
| Bolt-4830 | 3/8"-16 | 1.50" | 9/16" | 15/64" | 5 | $27.07 | Add to Order |
| Bolt-4831 | 3/8"-16 | 1.75" | 9/16" | 15/64" | 5 | $28.58 | Add to Order |
| Bolt-4832 | 3/8"-16 | 2.00" | 9/16" | 15/64" | 5 | $31.58 | Add to Order |
| Bolt-4833 | 3/8"-16 | 3.00" | 9/16" | 15/64" | 5 | $33.60 | Add to Order |
| Bolt-4834 | 3/8"-16 | 4.00" | 9/16" | 15/64" | 5 | $44.60 | Add to Order |
| Bolt-4835 | 3/8"-16 | 5.00" | 9/16" | 15/64" | 5 | $65.50 | Add to Order |
| Bolt-4836 | 3/8"-16 | 6.00" | 9/16" | 15/64" | 5 | $72.20 | Add to Order |
| Bolt-4837 | 1/2"-13 | .750" | 3/4" | 5/16" | 5 | $35.00 | Add to Order |
| Bolt-4838 | 1/2"-13 | 1.00" | 3/4" | 5/16" | 5 | $37.90 | Add to Order |
| Bolt-4839 | 1/2"-13 | 1.25" | 3/4" | 5/16" | 5 | $43.30 | Add to Order |
| Bolt-4840 | 1/2"-13 | 1.50" | 3/4" | 5/16" | 5 | $44.70 | Add to Order |
| Bolt-4841 | 1/2"-13 | 1.75" | 3/4" | 5/16" | 5 | $47.60 | Add to Order |
| Bolt-4842 | 1/2"-13 | 2.00" | 3/4" | 5/16" | 5 | $54.00 | Add to Order |
| Bolt-4843 | 1/2"-13 | 2.50" | 3/4" | 5/16" | 5 | $62.50 | Add to Order |
| Bolt-4844 | 1/2"-13 | 3.00" | 3/4" | 5/16" | 5 | $69.93 | Add to Order |
| Bolt-4845 | 1/2"-13 | 3.50" | 3/4" | 5/16" | 5 | $76.13 | Add to Order |
| Bolt-4846 | 1/2"-13 | 4.00" | 3/4" | 5/16" | 5 | $88.10 | Add to Order |
| Bolt-4847 | 3/4"-10 | 1.50" | 1-1/8" | 15/32" | 1 | $26.75 | Add to Order |
| Bolt-4848 | 3/4"-10 | 2.00" | 1-1/8" | 15/32" | 1 | $32.57 | Add to Order |
| Rev. 04-23, 11-22, 02-22, 07-21 | |||||||
