Extreme Strength Stainless 12 Point Bolts
Extreme Strength Stainless Steel, RH Threads
| Part # | Thread Size | Overall Length | Flange Diameter | Head Width | Head Height | Pkg. Qty. | Pkg. Price | Order Online |
|---|---|---|---|---|---|---|---|---|
| 304 Stainless Steel, Fully Threaded | ||||||||
| Bolt-090 | 1/4"-20 | .500" | .515" | .312" | .250" | 5 | $24.78 | Add to Order |
| Bolt-091 | 1/4"-20 | .750" | .515" | .312" | .250" | 5 | $26.67 | Add to Order |
| Bolt-092 | 1/4"-20 | 1.00" | .515" | .312" | .250" | 5 | $29.40 | Add to Order |
| Bolt-109 | 5/16"-18 | .562" | .625" | .375" | .312" | 5 | $27.93 | Add to Order |
| Bolt-110 | 5/16"-18 | .750" | .625" | .375" | .312" | 5 | $29.40 | Add to Order |
| Bolt-111 | 5/16"-18 | 1.00" | .625" | .375" | .312" | 5 | $31.71 | Add to Order |
| Bolt-126 | 3/8"-16 | .500" | .625" | .375" | .312" | 5 | $31.29 | Add to Order |
| Bolt-127 | 3/8"-16 | .750" | .625" | .375" | .312" | 3 | $19.78 | Add to Order |
| Bolt-128 | 3/8"-16 | 1.00" | .625" | .375" | .312" | 5 | $35.28 | Add to Order |
| 450 Stainless Steel, 1" Partially Threaded | ||||||||
| Bolt-093 | 1/4"-20 | 1.25" | .515" | .312" | .250" | 5 | $29.40 | Add to Order |
| Bolt-094 | 1/4"-20 | 1.50" | .515" | .312" | .250" | 5 | $40.53 | Add to Order |
| Bolt-095 | 1/4"-20 | 1.75" | .515" | .312" | .250" | 5 | $60.27 | Add to Order |
| Bolt-096 | 1/4"-20 | 2.00" | .515" | .312" | .250" | 5 | $42.63 | Add to Order |
| Bolt-097 | 1/4"-20 | 2.25" | .515" | .312" | .250" | 5 | $43.47 | Add to Order |
| Bolt-098 | 1/4"-20 | 2.50" | .515" | .312" | .250" | 5 | $44.31 | Add to Order |
| Bolt-099 | 1/4"-20 | 2.75" | .515" | .312" | .250" | 5 | $44.94 | Add to Order |
| Bolt-100 | 1/4"-20 | 3.00" | .515" | .312" | .250" | 5 | $45.78 | Add to Order |
| Bolt-101 | 1/4"-28 | 1.25" | .515" | .312" | .250" | 5 | $29.40 | Add to Order |
| Bolt-102 | 1/4"-28 | 1.50" | .515" | .312" | .250" | 5 | $40.53 | Add to Order |
| Bolt-103 | 1/4"-28 | 1.75" | .515" | .312" | .250" | 5 | $42.17 | Add to Order |
| Bolt-104 | 1/4"-28 | 2.00" | .515" | .312" | .250" | 5 | $42.63 | Add to Order |
| Bolt-105 | 1/4"-28 | 2.25" | .515" | .312" | .250" | 5 | $43.47 | Add to Order |
| Bolt-106 | 1/4"-28 | 2.50" | .515" | .312" | .250" | 5 | $44.31 | Add to Order |
| Bolt-107 | 1/4"-28 | 2.75" | .515" | .312" | .250" | 5 | $44.94 | Add to Order |
| Bolt-108 | 1/4"-28 | 3.00" | .515" | .312" | .250" | 5 | $45.78 | Add to Order |
| Bolt-112 | 5/16"-18 | 1.50" | .625" | .375" | .312" | 5 | $46.20 | Add to Order |
| Bolt-113 | 5/16"-18 | 1.75" | .625" | .375" | .312" | 3 | $29.11 | Add to Order |
| Bolt-114 | 5/16"-18 | 2.00" | .625" | .375" | .312" | 3 | $30.24 | Add to Order |
| Bolt-115 | 5/16"-18 | 2.25" | .625" | .375" | .312" | 3 | $31.75 | Add to Order |
| Bolt-116 | 5/16"-18 | 2.50" | .625" | .375" | .312" | 3 | $32.26 | Add to Order |
| Bolt-117 | 5/16"-18 | 2.75" | .625" | .375" | .312" | 3 | $33.01 | Add to Order |
| Bolt-118 | 5/16"-18 | 3.00" | .625" | .375" | .312" | 3 | $33.77 | Add to Order |
| Bolt-119 | 5/16"-24 | 1.50" | .625" | .375" | .312" | 3 | $27.72 | Add to Order |
| Bolt-120 | 5/16"-24 | 1.75" | .625" | .375" | .312" | 3 | $28.98 | Add to Order |
| Bolt-121 | 5/16"-24 | 2.00" | .625" | .375" | .312" | 3 | $30.24 | Add to Order |
| Bolt-122 | 5/16"-24 | 2.25" | .625" | .375" | .312" | 3 | $31.75 | Add to Order |
| Bolt-123 | 5/16"-24 | 2.50" | .625" | .375" | .312" | 3 | $32.26 | Add to Order |
| Bolt-124 | 5/16"-24 | 2.75" | .625" | .375" | .312" | 3 | $33.01 | Add to Order |
| Bolt-125 | 5/16"-24 | 3.00" | .625" | .375" | .312" | 3 | $33.77 | Add to Order |
| 450 Stainless Steel, 1-1/8" Partially Threaded | ||||||||
| Bolt-126 | 3/8"-16 | 0.50" | .625" | .375" | .312" | 5 | $31.29 | Add to Order |
| Bolt-127 | 3/8"-16 | 0.75" | .625" | .375" | .312" | 3 | $19.78 | Add to Order |
| Bolt-129 | 3/8"-16 | 1.50" | .625" | .375" | .312" | 3 | $30.49 | Add to Order |
| Bolt-130 | 3/8"-16 | 1.75" | .625" | .375" | .312" | 3 | $32.13 | Add to Order |
| Bolt-131 | 3/8"-16 | 2.00" | .625" | .375" | .312" | 3 | $33.52 | Add to Order |
| Bolt-132 | 3/8"-16 | 2.25" | .625" | .375" | .312" | 3 | $34.52 | Add to Order |
| Bolt-133 | 3/8"-16 | 2.50" | .625" | .375" | .312" | 3 | $35.03 | Add to Order |
| Bolt-134 | 3/8"-16 | 2.75" | .625" | .375" | .312" | 3 | $37.17 | Add to Order |
| Bolt-135 | 3/8"-16 | 3.00" | .625" | .375" | .312" | 3 | $54.87 | Add to Order |
| Bolt-136 | 3/8"-24 | 1.50" | .625" | .375" | .312" | 3 | $30.49 | Add to Order |
| Bolt-137 | 3/8"-24 | 1.75" | .625" | .375" | .312" | 3 | $32.13 | Add to Order |
| Bolt-138 | 3/8"-24 | 2.00" | .625" | .375" | .312" | 3 | $33.60 | Add to Order |
| Bolt-139 | 3/8"-24 | 2.25" | .625" | .375" | .312" | 3 | $34.52 | Add to Order |
| Bolt-140 | 3/8"-24 | 2.50" | .625" | .375" | .312" | 3 | $35.03 | Add to Order |
| Bolt-141 | 3/8"-24 | 2.75" | .625" | .375" | .312" | 3 | $37.17 | Add to Order |
| Bolt-142 | 3/8"-24 | 3.00" | .625" | .375" | .312" | 3 | $38.30 | Add to Order |
| Rev. 03-24, 01-24, 04-23, 03-22 | ||||||||
